Image Sensor

1/2.7” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Aperture

F1.6

Lens

4 mm, Fixed Focal Lens, M12

FOV

Horizontal FOV: 88°, Vertical FOV: 46°, Diagonal FOV: 105.4°

Minimum Illumination

0.005 Lux; 0 Lux with IR/White Light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Auto

White LED

• Quantity: 4

• Range: 98 ft (30m)

IR LED

• Quantity: 4

• Range: 98 ft (30 m)

• Wavelength: 850nm

Illuminator On/Off Control

Auto/Always on/Always off

Max. Resolution

3840 x 2160 (8MP)

Main Stream

• Frame Rate:

50Hz: 25fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)

60Hz: 24fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)

• Note:

If the image rotation is set to 90° or 270°, the frame rate only supports up to   20fps.

If 120dB WDR is turned on, the frame rate can only support up to 20fps.

Sub-Stream

• Frame Rate：

50Hz: 25fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)

60Hz: 24fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)

• Note:

If the image rotation is set to 90° or 270°, the frame rate only supports up to   20fps.

If 120dB WDR is turned on, the frame rate can only support up to 20fps.

Video Bit Rate

• Main Stream: 256 Kbps to 8192 Kbps

• Sub-Stream: 64 Kbps to 1024 Kbps

Video Compression

• Main Stream: H.265+/H.265/H.264+/H.264

• Sub-Stream: H.265/H.264

Event

• Motion Detection (Person/Vehicle/Pet Detection)

• Line-Crossing Detection (Person/Vehicle/Pet Detection)

• Intrusion Detection (Person/Vehicle/Pet Detection)

• Camera Tampering

Recording Modes

Event-Triggered   Recording, Scheduled Recording, 24/7 Recording (Default)

Interface & Button

• Buit-in Microphone; Records Anything Going on within a 16.4ft (5m) Radius of the Camera

• Buit-in Speaker

• 1× RJ45 10/100Mbps Self-Adaptive Ethernet Port, PoE

• 1× DC Port

• Reset Button

• Red & Blue Warning Lights

• Buit-in Memory Card Slot, Support MicroSD Card, up to 512GB△

*The microSD card is not included in the package.

Operating Temperature

-30 °C to 60 °C (-22 ℉ to 140 ℉)

Operating Humidity

95% or Less (Non-Condensing)

Power Supply

DC

• 12V DC ± 5%, Max. 12 W, 5.5 mm Coaxial Power Plug

• Recommended Power Supply: T120100-2C1 (for EU Regions)

PoE

• PoE: 802.3af/at, Max. 12.5 W

ErP Information

• Power consumption in networked standby when all wired network ports are   connected and all wireless network ports are activated: 2.7 W

Protection

• IP67 Weatherproof

• IK08 Vandal Proof

Product Dimensions (L x W x H)

4.4 ×  4.4  × 3.5 in (112 × 112 × 88 mm)

Weight

Net Weight: 0.5 kg (1.10 lbs)

NVR

IP Video Input

16-Channel*

Managed Cameras

• 16 (HD)

• 16 (2K/5MP)

• 12 (4K/8MP)

• 8 (12MP)

• 6 (16MP)

HDMI Output Resolution

1 Channel, Resolution: 3840x2160/30Hz, 2560x1440/60Hz, 1920x1080/60Hz,   1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz

VGA Output Resolution

1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz,   1280x1024/60Hz, 1280x720/60Hz

Video Compression

H.265+/H.265/H.264+/H.264

Record Resolution

16MP / 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF/ QCIF

Synchronous Playback

16-Channel

Decoding Capability

• 25fps:

10-ch @ 2MP

• 30fps:

1-ch @ 16MP, 2-ch @ 8MP, 4-ch @ 5MP, 5-ch @ 4MP, 6-ch @ 3MP

Hard Disk

• 1× SATA Interface, Up to 16 TB Capacity

• 1× 4TB HDD Preinstalled

PoE Budget

115 W Available for All PoE+ Ports, 30 W Max per Port

External Interfaces

• 1× eSATA, Supports External Storage Devices up to 16TB

• 1× HDMI Port

• 1× VGA Port

• 1× Front USB 2.0 Port, 1× Rear USB 3.0 Port

• 1-ch RCA Audio Input (1.4 Vp-p, 10KΩ), 1-ch RCA Audio Output (2.8 Vp-p, 1KΩ)

• 1× 10/100/1000 Mbps Self-Adaptive Ethernet Port

• 1× DC Power Supply Port

• 8× PoE+ Ports

Network Protocol

• UPnP (Plug and Play)

• NTP (Network Timing)

• SMTP

• DNS

• TCP/IP

• UDP

• ICMP

• HTTP

• HTTPS

• DHCP

• RTSP

• SSL/TLS

• RTP

• IPv4

• ARP

• LLDP

• FTP

• IPv6

• SNMP

Web Browser

• Chrome (57+)

• Firefox (52+)

• Edge (91+)

Max. User Access

40 Users; Support up to 32 Simultaneous Video Streams

Power Supply

53.5V DC/2.43 A

Working Temperature

• NVR: -10 °C to 55 °C (14 ℉ to 131 ℉）

• Power Adapter: 0 °C to 40 °C (32 ℉ to 104 ℉)

Interoperability

ONVIF Profile G/S/T

Product Dimensions (L x W x H)

10.2 × 9.1 × 1.8 in (260 ×  230  × 45 mm)

Weight

Net Weight: 2.23 Kg (4.92 lbs)
