Image Sensor

1/2.7” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Aperture

F1.6

Lens

4 mm, Fixed Focal Lens

FOV

Horizontal FOV: 88°, Vertical FOV: 46.0°, Diagonal FOV: 105.4°

Minimum Illumination

0.005 Lux; 0 Lux with IR/White Light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Auto

White LED

• Quantity: 2

• Range: 98 ft (30m)

IR LED

• Quantity: 2

• Range: 98 ft (30 m)

• Wavelength: 850nm

Illuminator On/Off Control

Auto/Always on/Always off

Max. Resolution

3840 x 2160 (8MP)

Main Stream

• Frame Rate:

50Hz: 25fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)

60Hz: 24fps (3840x2160, 2560x1440, 2304x1296, 2048x1280,1920x1080)

• Note:

If the image rotation is set to 90° or 270°, the frame rate only supports up to   20fps.

If 120dB WDR is turned on, the frame rate can only support up to 20fps.

Sub-Stream

• Frame Rate：

50Hz: 25fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)

60Hz: 24fps (840x480,704x576,640x480, 640x360, 352x288, 320x240)

• Note:

If the image rotation is set to 90° or 270°, the frame rate only supports up to   20fps.

If 120dB WDR is turned on, the frame rate can only support up to 20fps.

Video Bit Rate

• Main Stream: 256 Kbps to 8192 Kbps

• Sub-Stream: 64 Kbps to 1024 Kbps

Video Compression

• Main Stream: H.265+/H.265/H.264+/H.264

• Sub-Stream: H.265/H.264

Event

• Motion Detection (People Detection, Vehicle Detection, Pet Detection)

• Intrusion Detection (People Detection, Vehicle Detection, Pet Detection)

• Line-Crossing Detection (People Detection, Vehicle Detection, Pet Detection)

• Camera Tampering

Recording Modes

Event-Triggered  Recording, Scheduled Recording, 24/7 Recording (Default)

Interface & Button

• Buit-in Microphone; Records Anything Going on within a 16.4ft (5m) Radius of the Camera

• Buit-in Speaker

• 1× RJ45 10/100Mbps Self-Adaptive Ethernet Port, PoE

• 1× DC Port

• Reset Button

• Red & Blue Warning Lights

• Buit-in Memory Card Slot, Support MicroSD Card, up to 521GB*

*The microSD card is not included in the package.

Operating Temperature

-30 ℃ to 60 °C (-22 °F to 140 °F)

Operating Humidity

95% or Less (Non-Condensing)

Power Supply

DC

• 12V DC ± 5%, Max. 10.5 W, 5.5 mm Coaxial Power Plug

• Recommended Power Supply: T120100-2C1 (for EU Regions)

PoE

• PoE: 802.3af/at, Max. 12 W

ErP Information

• Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 2.7 W

Protection

• IP67 Weatherproof

• IK10 Vandal Proof

Product Dimensions (L x W x H)

8.3 × 2.9  × 3.1 in (210 × 74 × 78 mm)

Weight

Net Weght: 0.6 Kg (1.32 lbs)

NVR

IP Video Input

16-Channel**

**The NVR's eight PoE ports support direct connection to eight wired cameras. To add eight more wired or wireless cameras, ensure all devices (NVR and cameras) are on the same LAN.

Managed Cameras

• 16 (HD)

• 16 (2K/5MP)

• 12 (4K/8MP)

• 8 (12MP)

• 6 (16MP)

HDMI Output Resolution

1 Channel, Resolution: 3840x2160/30Hz, 2560x1440/60Hz, 1920x1080/60Hz,   1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz

VGA Output Resolution

1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz,   1280x1024/60Hz, 1280x720/60Hz

Video Compression

H.265+/H.265/H.264+/H.264

Record Resolution

16MP / 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF /   2CIF / CIF/ QCIF

Synchronous Playback

16-Channel

Decoding Capability

• 25fps:

10-ch @ 1080P

• 30fps:

1-ch @ 16MP, 2-ch @ 8MP, 4-ch @ 5MP, 5-ch @ 4MP, 6-ch @ 3MP

Hard Disk

• 1× SATA Interface, Up to 16 TB Capacity

• 1× 2TB HDD Preinstalled

PoE Budget

115 W Available for All PoE+ Ports, 30 W Max per Port

External Interfaces

• 1× eSATA, Supports External Storage Devices up to 16TB

• 1× HDMI Port

• 1× VGA Port

• 1× Front USB 2.0 Port, 1× Rear USB 3.0 Port

• 1-ch RCA Audio Input (1.4 Vp-p, 10KΩ), 1-ch RCA Audio Output (2.8 Vp-p, 1KΩ)

• 1× 10/100/1000 Mbps Self-Adaptive Ethernet Port

• 1× DC Power Supply Port

• 8× PoE+ Ports

Network Protocol

• UPnP (Plug and Play)

• NTP (Network Timing)

• SMTP

• DNS

• TCP/IP

• UDP

• ICMP

• HTTP

• HTTPS

• DHCP

• RTSP

• SSL/TLS

• RTP

• IPv4

• ARP

• LLDP

• FTP

• IPv6

• SNMP

Web Browser

• Chrome (57+)

• Firefox (52+)

• Edge (91+)

Max. User Access

40 Users; Support up to 32 Simultaneous Video Streams

Power Supply

53.5V   DC/1.31 A

Working Temperature

• NVR: -10 ℃ to 55 °C (14 °F to 131 °F）

• Power Adapter: 0 ℃ to 40 °C (32 °F to 104 °F)

Interoperability

ONVIF Profile G/S/T

Product Dimensions (L x W x H)

10.2 × 9.1 × 1.8 in (260 × 230 × 45 mm)

Weight

Net Weight: 1.86 Kg (4.1 lbs)
