Image Sensor

1/2.65” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Aperture

F1.6

Lens

4 mm, Fixed Focal Lens, M12

FOV

Horizontal FOV: 92°, Vertical FOV: 48°, Diagonal FOV: 110°

Minimum Illumination

0.005 Lux; 0 Lux with IR/White Light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Auto

Integrated Infrared-White LED

• Quantity: 2

• IR Range: 98 ft (30 m)

• White LED Range: 98 ft (30 m)

• IR Wavelength: 850 nm

Illuminator On/Off Control

Auto/Always on/Always off

Max. Resolution

2880 x 1620 (5MP)

Main Stream

• Frame Rate:

50Hz: 25fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720)

60Hz: 30fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720)

Sub-Stream

• Frame Rate:

50Hz: 25fps (848x480,704x576, 640x480, 640x360,352x288, 320x240)

60Hz: 30fps (848x480,704x576, 640x480, 640x360,352x288, 320x240)

Video Bit Rate

• Main Stream: 256 Kbps to 6144 Kbps

• Sub-Stream: 64 Kbps to 512 Kbps

Video Compression

• Main Stream: H.265+/H.265/H.264+/H.264

• Sub-Stream: H.265/H.264

Event

• Motion Detection (People Detection, Vehicle Detection, Pet Detection)

• Intrusion Detection (People Detection, Vehicle Detection, Pet Detection)

• Line-Crossing Detection (People Detection, Vehicle Detection, Pet Detection)

• Video Tampering Detection

Recording Modes

N/A

Interface & Button

• Buit-in Microphone; Records Anything Going on within a 16.4ft (5m) Radius of the Camera

• 1× RJ45 10/100Mbps Self-Adaptive Ethernet Port, PoE

• 1× DC Port

Operating Temperature

-30 °C to 60 °C (-22 °F to 140 °F)

Operating Humidity

95% or Less (Non-Condensing)

Power Supply

DC

• 12V DC ± 5%, Max. 7.4 W, 5.5 mm Coaxial Power Plug

• Recommended Power Supply: T120100-2C1 (for EU Regions)

PoE

• PoE: 802.3af/at, Max. 8.7 W

ErP Information

• Power consumption in networked standby when all wired network ports are   connected and all wireless network ports are activated: 2.2 W

Protection

• IP67 Weatherproof

• IK08 Vandal Proof

Product Dimensions (L x W x H)

4.4 × 4.4 × 3.4 in (112 × 112 × 87 mm)

Weight

Net Weight: 0.45 kg (0.99 lbs)

NVR

IP Video Input

16-Channel**

**The NVR's eight PoE ports support direct connection to eight wired cameras. To   add eight more wired orwireless cameras, ensure all devices (NVR and cameras)   are on the same LAN.

Managed Cameras

• 16 (HD)

• 16 (2K/5MP)

• 12 (4K/8MP)

• 8 (12MP)

• 6 (16MP)

HDMI Output Resolution

1 Channel, Resolution: 3840x2160/30Hz, 2560x1440/60Hz, 1920x1080/60Hz,   1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz

VGA Output Resolution

1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz,   1280x1024/60Hz, 1280x720/60Hz

Video Compression

H.265+/H.265/H.264+/H.264

Record Resolution

16MP / 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF/ QCIF

Synchronous Playback

16-Channel

Decoding Capability

• 25fps:

10-ch @ 2MP

• 30fps:

1-ch @ 16MP, 2-ch @ 8MP, 4-ch @ 5MP, 5-ch @ 4MP, 6-ch @ 3MP

Hard Disk

• 1× SATA Interface, Up to 16 TB Capacity

• 1× 2TB HDD Preinstalled

PoE Budget

115 W Available for All PoE+ Ports, 30 W Max per Port

External Interfaces

• 1× eSATA, Supports External Storage Devices up to 16TB

• 1× HDMI Port

• 1× VGA Port

• 1× Front USB 2.0 Port, 1× Rear USB 3.0 Port

• 1-ch RCA Audio Input (1.4 Vp-p, 10KΩ), 1-ch RCA Audio Output (2.8 Vp-p, 1KΩ)

• 1× 10/100/1000 Mbps Self-Adaptive Ethernet Port

• 1× DC Power Supply Port

• 8× PoE+ Ports

Network Protocol

• UPnP (Plug and Play)

• NTP (Network Timing)

• SMTP

• DNS

• TCP/IP

• UDP

• ICMP

• HTTP

• HTTPS

• DHCP

• RTSP

• SSL/TLS

• RTP

• IPv4

• ARP

• LLDP

• FTP

• IPv6

• SNMP

Web Browser

• Chrome (57+)

• Firefox (52+)

• Edge (91+)

Max. User Access

40 Users; Support up to 32 Simultaneous Video Streams

Power Supply

53.5V DC/2.43 A

Working Temperature

• NVR: -10 °C to 55 °C (14 ℉ to 131 ℉）

• Power Adapter: 0 °C to 40 °C (32 ℉ to 104 ℉)

Interoperability

ONVIF Profile G/S/T

Product Dimensions (L x W x H)

10.2 × 9.1 × 1.8 in (260 ×  230  × 45 mm)

Weight

Net Weight: 2.23 Kg (4.92 lbs)
