CAMERA |
|
Image Sensor | 1/2.65” Progressive Scan CMOS |
Shutter Speed | 1/3 to 1/10000 s |
Aperture | F1.6 |
Lens | 4 mm, Fixed Focal Lens, M12 |
FOV | Horizontal FOV: 92°, Vertical FOV: 48°, Diagonal FOV: 110° |
Minimum Illumination | 0.005 Lux; 0 Lux with IR/White Light |
Day/Night Mechanism | IR Cut Filter |
Day/Night Switch | Auto |
Integrated Infrared-White LED | • Quantity: 2 • IR Range: 98 ft (30 m) • White LED Range: 98 ft (30 m) • IR Wavelength: 850 nm |
Illuminator On/Off Control | Auto/Always on/Always off |
Max. Resolution | 2880 x 1620 (5MP) |
Main Stream | • Frame Rate: 50Hz: 25fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720) 60Hz: 30fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720) |
Sub-Stream | • Frame Rate: 50Hz: 25fps (848x480,704x576, 640x480, 640x360,352x288, 320x240) 60Hz: 30fps (848x480,704x576, 640x480, 640x360,352x288, 320x240) |
Video Bit Rate | • Main Stream: 256 Kbps to 6144 Kbps • Sub-Stream: 64 Kbps to 512 Kbps |
Video Compression | • Main Stream: H.265+/H.265/H.264+/H.264 • Sub-Stream: H.265/H.264 |
Event | • Motion Detection (People Detection, Vehicle Detection, Pet Detection) • Intrusion Detection (People Detection, Vehicle Detection, Pet Detection) • Line-Crossing Detection (People Detection, Vehicle Detection, Pet Detection) • Video Tampering Detection |
Recording Modes | N/A |
Interface & Button | • Buit-in Microphone; Records Anything Going on within a 16.4ft (5m) Radius of the Camera • 1× RJ45 10/100Mbps Self-Adaptive Ethernet Port, PoE • 1× DC Port |
Operating Temperature | -30 °C to 60 °C (-22 °F to 140 °F) |
Operating Humidity | 95% or Less (Non-Condensing) |
Power Supply | DC • 12V DC ± 5%, Max. 7.4 W, 5.5 mm Coaxial Power Plug • Recommended Power Supply: T120100-2C4 (for EU Regions) PoE • PoE: 802.3af/at, Max. 8.7 W ErP Information • Power consumption in networked standby when all wired network ports are connected and all wireless network ports are activated: 2.3 W |
Protection | • IP67 Weatherproof • IK10 Vandal Proof |
Product Dimensions (L x W x H) | 6.7 × 2.9 × 2.9 in (169.8 × 74 × 74 mm) |
Weight | Net Weight: 0.42 kg (0.93 lbs) |
NVR |
|
IP Video Input | 16-Channel** |
Managed Cameras | • 16 (HD) • 16 (2K/5MP) • 12 (4K/8MP) • 8 (12MP) • 6 (16MP) |
HDMI Output Resolution | 1 Channel, Resolution: 3840x2160/30Hz, 2560x1440/60Hz, 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
VGA Output Resolution | 1 Channel, Resolution: 1920x1080/60Hz, 1680x1050/60Hz, 1440x900/60Hz, 1280x1024/60Hz, 1280x720/60Hz |
Video Compression | H.265+/H.265/H.264+/H.264 |
Record Resolution | 16MP / 12MP / 8MP / 5MP / 4MP / 3MP / 1080p / UXGA / 720p / VGA / 4CIF / DCIF / 2CIF / CIF/ QCIF |
Synchronous Playback | 16-Channel |
Decoding Capability | • 25fps: 10-ch @ 2MP • 30fps: 1-ch @ 16MP, 2-ch @ 8MP, 4-ch @ 5MP, 5-ch @ 4MP, 6-ch @ 3MP |
Hard Disk | • 1× SATA Interface, Up to 16 TB Capacity • 1× 2TB HDD Preinstalled |
PoE Budget | 115 W Available for All PoE+ Ports, 30 W Max per Port |
External Interfaces | • 1× eSATA, Supports External Storage Devices up to 16TB • 1× HDMI Port • 1× VGA Port • 1× Front USB 2.0 Port, 1× Rear USB 3.0 Port • 1-ch RCA Audio Input (1.4 Vp-p, 10KΩ), 1-ch RCA Audio Output (2.8 Vp-p, 1KΩ) • 1× 10/100/1000 Mbps Self-Adaptive Ethernet Port • 1× DC Power Supply Port • 8× PoE+ Ports |
Network Protocol | • UPnP (Plug and Play) • NTP (Network Timing) • SMTP • DNS • TCP/IP • UDP • ICMP • HTTP • HTTPS • DHCP • RTSP • SSL/TLS • RTP • IPv4 • ARP • LLDP • FTP • IPv6 • SNMP |
Web Browser | • Chrome (57+) • Firefox (52+) • Edge (91+) |
Max. User Access | 40 Users; Support up to 32 Simultaneous Video Streams |
Power Supply | 53.5V DC/2.43 A |
Working Temperature | • NVR: -10 °C to 55 °C (14 °F to 131 °F） • Power Adapter: 0 °C to 40 °C (32 °F to 104 °F) |
Interoperability | ONVIF Profile G/S/T |
Product Dimensions (L x W x H) | 10.2 × 9.1 × 1.8 in (260 × 230 × 45 mm) |
Weight | Net Weight: 2.23 Kg (4.92 lbs) |
