Product Type

microSDHC Memory Card

Application

Surveillance & Security (IP/Home/Network) cams, Dash cams, Body cams, and other always-on applications.

Rated Capacity

32GB, (1GB=1,000,000,000 bytes)

* Actual usable storage capacity is measured with SD Formatter 3.1 tool with exFAT file system and may be less than labeled capacity.

Interface

UHS-I SDR104

* SDR104: 1.8V Signaling, Frequency up to 208 MHz, speeds up to 104 MB/sec, max. power consumption 800mA (varies by test conditions).

Dimension (WxHxD)

15 x 11 x 1 (mm)

Weight

Approx. 0.5g

Accessory

SD adapter

RELIABILITY

Endurance

Up to 17,520 hours (or 2 years) of Full HD recording

* Based on Full HD (1920x1080) video content recorded at 26 Mbps Video support.

PERFORMANCE

Speed

Read : up to 100 MB/s, Write : up to 30MB/s

* Performance results are based on internal testing conditions. Read/write speeds may vary by host device.

Speed Class

Class 10

ENVIRONMENT

4-proof

1) Temperatures : Withstands -25°C to 85°C (-13°F to 185°F) operating, -40°C to 85°C (-40°F to 185°F) non-operating
2) Water : IEC60529, IPX7 / up to 72 hours in salt water
3) X-ray : Airport X-ray machines (up to 50 Roentgen)
4) Magnet : The equivalent of a high-field MRI scanner (up to 15,000 gauss)

Operating Voltage

2.7~3.6V

Humidity

Up to 40'C, 93%, 500hr (storage)

Durability

Up to 10,000 insertion/removal cycles

CERTIFICATION

EMC

FCC, CE, VCCI, NATA

DISCLAIMER

1) Samsung is not liable for any damages and/or loss of data or expenses incurred due to memory card data recovery. The results are based on internal tests, features and specs may vary by actual usage conditions.

2) The Samsung product authentication for memory cards and USB flash drives is available at: www.samsung.com/support
