CPU

• Intel® Core™ i3-8100T 4-core 3.1 GHz processor

• Architecture: 64-bit

• Graphics: Intel® UHD Graphics 630

Encryption Acceleration

• (AES-NI)

System Memory

• 8 GB SODIMM DDR4 (2 x 4 GB)

Maximum Memory

• 32 GB ( 2 x 16 GB)

Memory Slot

• 2 x SO-DIMM DDR4

• (For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.)

Flash Memory

• 4 GB (Dual boot OS protection)

Drive Bay

• Hot-swappable 6 x 3.5-inch SATA 6 Gbps bays

Drive Compatibility

• 3.5-inch bays: 3.5-inch SATA hard disk drives

•                        2.5-inch SATA hard disk drives

•                        2.5-inch SATA solid state drives

M.2 SSD Slot

• 2 x M.2 2280 PCIe (Gen3 x2) NVMe slots

Thunderbolt Port

• 2 x Thunderbolt™ 3 ports

10 Gigabit Ethernet Port

• 1 x 10GBASE-T RJ45, supporting 10G/5G/2.5G/1G/100M

• Note: Please use CAT6a or CAT 7 LAN cables (sold separately) to achieve 10GbE speed

• Gigabit Ethernet Port

• 2 x RJ45

PCIe Slot

• Slot 1: PCIe Gen3 x16 (CPU)

• Slot 2: PCIe Gen3 x4 (PCH)

• Note: Slot 1 is pre-installed with a Thunderbolt 3 adapter

USB Port

• 1 x USB 3.0

• 2 x Type-C USB 3.1 Gen2 5V/3A 10Gbps

• 2 x Type-A USB 3.1 Gen2 5V/1A 10Gbps

HDMI Output

• 1 x HDMI 2.0, up to 3840 x 2160, @60Hz

Audio

• 1 x 3.5 mm dynamic microphone jack

• 1 x 3.5 mm line-out jack

• 1 x speaker

• Note: You cannot use the speakers and the line-out jack simultaneously.

IR sensor

• supports QNAP RM-IR004 remote control

LED Indicators

• HDD 1-6, Status, LAN, USB port, M.2 port

Buttons

• Power, Reset, USB One-touch-copy

Form Factor

• Tower

Dimensions (H x W x D)

• 188.2 x 264.3 x 279.6 mm

• 7.4 x 10.4 x 11 inch

Weight Net

• 6.55 kg (14.4 lbs)

• Gross: 8.07 kg (17.79 lbs)

• Power Supply Unit

• 250W, 100-240V

Power Consumption (W)

• HDD standby: 26.52 W

• In operation: 45.6 W

• (with WD10EFRX drives fully populated)

Fan

• System: 2 x 9.2cm fan (12V DC)

• CPU: 2 x 6cm blower fan

Sound Level

• Sound pressure (LpAm): 23.8 dB(A)

System Warning

• Voice prompts or Buzzer

Operating Temperature & Relative Humidity

• 0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Security Slot

• Kensington security slot
