CPU Architecture

64-bit x86

Graphic Processors

Intel® HD Graphics 600

Floating Point Unit

✓

Encryption Engine

 ✓ (AES-NI)

Hardware-accelerated Transcoding

✓

System Memory

4 GB SODIMM DDR4 (1 x 4 GB)

Maximum Memory

8 GB (2 x 4GB)

Memory Slot

2 x SODIMM DDR4

For dual-DIMM configuration, you must use a pair of identical DDR4 modules.

Flash Memory

4GB (Dual boot OS protection)

Drive Bay

2 x 3.5-inch SATA 6Gb/s, 3Gb/s

The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/

Drive Compatibility

3.5-inch SATA hard disk drives
  2.5-inch SATA hard disk drives
  2.5-inch SATA solid state drives

Hot-swappable

✓

M.2 Slot

Optional via a PCIe adapter

SSD Cache Acceleration Support

✓

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

2 (2.5G/1G/100M/10M)

5 Gigabit Ethernet Port (5G/2.5G/1G/100M)

Optional via PCIe expansion card

10 Gigabit Ethernet Port

Optional via PCIe expansion card

Optional via PCIe expansion card

Wake on LAN (WOL)

Only the 2.5GbE port

Jumbo Frame

✓

PCIe Slot

1
Slot 1: PCIe Gen 2 x4

PCIe bandwidth limitations will restrict   the NAS 10GbE performance.
Card dimensions for PCIe slot：190 x 68.9x 18.76 mm / 7.48 x 2.71 x 0.74   inches.

USB 2.0 port

3

USB 3.2 Gen 1 port

2

USB 3.2 Gen 2 (10Gbps) Port

Optional via a PCIe expansion card

IR Sensor

 ✓ (Optional QNAP RM-IR004 remote control)

HDMI Output

1, HDMI 2.0 (up to 4096 x 2160 @ 60Hz)

Form Factor

Tower

LED Indicators

Power/Status, LAN, USB, HDD1-2

Buttons

Power, USB copy, Reset

Dimensions (HxWxD)

168 × 105 × 226 mm

Weight (Net)

1.55 kg

Weight (Gross)

2.68 kg

Operating Temperature

0 - 40 °C (32°F - 104°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C   (80.6˚F)

Power Supply Unit

65W adapter (12VDC), 100-240VAC

Power Consumption: HDD Sleep Mode

8.198 W

Power Consumption: Operating Mode, Typical

12.448 W

Tested with drives fully populated.

Fan

1 x 70mm, 12VDC

System Warning

Buzzer

Kensington Security Slot

✓

Max. Number of Concurrent Connections (CIFS)

with Max. Memory

1500
