Folded size:

301 x 207 x 84 mm

Unfolded size:

347 x 208 x 167 mm

Weight:

1171 g

Technical

WIFI Technology:

WIFI 6 (802.11ax) Tri-Band WIFI (AX6600).

·          2.4GHz AX: 2x2 (Tx/Rx) 1024/256 QAM   20/40MHz, up to 0.6Gbps.

·          5GHz AX: 2x2 (Tx/Rx) 1024/256 QAM   20/40/80MHz, up to 1.2Gbps.

·          5GHz AX: 4x4 (Tx/Rx) 1024/256 QAM   20/40/80/160MHz, up to 4.8Gbps.

Backwards compatible with 802.11a/b/g/n/ac WIFI.

WIFI Performance:

AX6600 WIFI

WIFI Range:

WIFI coverage for very large homes

WIFI Band:

Tri-Band 2.4 & 5GHz & 5GHz

Beamforming:

Beamforming+ — Boost’s speed, reliability and range   of WIFI connections for 2.4 and 5GHz

Ethernet Ports:

·          Five (5) 10/100/1000 Mbps Gigabit   Ethernet ports.

·          Dual Gigabit Ethernet port aggregation

USB Ports:

One (1) USB 3.0 port

Processor:

Powerful quad-core 1.5GHz processor

WIFI Speed:

·          1.2 + 4.8 Gbps + 600Mbps with 8-stream   connectivity**.

·          4X4 MU-MIMO allows simultaneous   streaming to multiple devices.

·          1024-QAM—25% increased data efficiency   and faster speeds than a 256-QAM router.

·          Ability to aggregate two gigabit LAN   ports for faster file transfers and two gigabit ports for internet   connections.

·          Multi-Gig Experience maximises your available   Internet speeds with link port aggregation support.

·          Ability to aggregate two Gigabit LAN   ports and two Gigabit WAN ports (configurable).

·          160MHZ channel support*** doubles the   speeds as offered by 80MHz channels to provide Gigabit speeds for compatible   mobile devices and laptops

WIFI Capacity:

·          4-stream MU-MIMO enables up to four   (4) 1x1 devices to stream content at the same time.

·          Robust quad-core 1.5GHz processor   boosts wireless, wired and WAN-TO-LAN performance.

Sharing:

·          One superspeed USB 3.0 port up to 10x   faster than USB 2.0. ReadySHARE® Vault for automatic PC backup to a USB hard   drive connected to the router.

·          ReadySHARE® USB access — Wirelessly   access & share USB hard drive via one (1) USB port

Ease of Use:

·          Smart Connect intelligently selects   fastest WIFI band for every device connection.

·          One WIFI name for the entire home.

·          Nighthawk App for easy router setup and   more, including access from anywhere to manage your network away from home.

·          AX WIFI supports all current WIFI   devices and is backward compatible with 802.11a/b/g/n/ac client devices.

·          Control NETGEAR network with simple   voice commands using Amazon Alexa and Google Assistant.

Security:

·          NETGEAR Armor provides advanced cyber   threat protection for your home and your connected devices.

·          Securely access home network &   internet connection from mobile devices with VPN support on PC, Mac, and iOS   and Android devices with OpenVPN Connect app.

·          Standards-based security —802.11i,   128-bit AES encryption with PSK.

·          Separate & secure access for guests.

·          Automatic firmware updates deliver   latest security patches to the router.
