Chipset

Intel® Z590   Express Chipset

Memory

11th   Generation Intel® Core™ i9/i7/i5 processors:

Support for   DDR4 5400 (O.C) / DDR4 5333(O.C.) / DDR4 5133(O.C.) / DDR4 5000(O.C.) /   4933(O.C.) / 4800(O.C.) / 4700(O.C.) / 4600(O.C.) / 4500(O.C.) / 4400(O.C.) /   4300(O.C.) /4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) /   3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) /   3300(O.C.) / 3200 / 3000 / 2933 / 2800 / 2666 / 2400 / 2133 MHz

10th   Generation Intel® Core™ i9/i7 processors:

Support for   DDR4 2933/2666/2400/2133 MHz memory modules

10th   Generation Intel® Core™ i5/i3 /Pentium®/Celeron® processors:

Support for   DDR4 2666/2400/2133 MHz memory modules

4 x DDR4 DIMM   sockets supporting up to 128 GB (32 GB single DIMM capacity) of system memory

Dual channel   memory architecture

Support for   ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode)

Support for   non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for   Extreme Memory Profile (XMP) memory modules

(Please refer   "Memory Support List" for more information.)

Onboard   Graphics

Integrated   Graphics Processor-Intel® HD Graphics support:

1 x   DisplayPort, supporting a maximum resolution of 4096x2304@60 Hz

* Support for   DisplayPort 1.2 version and HDCP 2.3

(Graphics   specifications may vary depending on CPU support.)

Audio

Realtek®   ALC4080 codec

High   Definition Audio

2/4/5.1/7.1-channel

Support for   S/PDIF Out

LAN

Intel® 2.5GbE   LAN chip (2.5 Gbit/1 Gbit/100 Mbit)

Wireless   Communication module

Intel® Wi-Fi   6 AX200

WIFI a, b, g,   n, ac, ax, supporting 2.4/5 GHz Dual-Band

BLUETOOTH 5.1

Support for   11ax 160MHz wireless standard and up to 2.4 Gbps data rate

* Actual data   rate may vary depending on environment and equipment.

Expansion   Slots

1 x PCI   Express x16 slot, running at x16 (PCIEX16)

* For optimum   performance, if only one PCI Express graphics card is to be installed, be   sure to install it in the PCIEX16 slot.

* The PCIEX16   slot shares bandwidth with the M2B_CPU and M2C_CPU connectors.

* The PCIEX16   slot operates at up to x8 mode when a device is installed in the M2B_CPU or   M2C_CPU connector.

(The PCIEX16   slot conforms to PCI Express 4.0 standard.)*

*Supported by   11th Generation processors only.

2 x PCI   Express x16 slots, running at x4 (PCIEX4_1/PCIEX4_2)

(PCIEX4_1 and   PCIEX4_2 slots conform to PCI Express 3.0 standard.)

Multi-Graphics   Technology

Support for   AMD Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

Storage   Interface

CPU:

1 x M.2   connector (Socket 3, M key, type 2242/2260/2280 PCIe 4.0 x4/x2 SSD support)   (M2A_CPU) *

2 x M.2   connectors (Socket 3, M key, type 2260/2280/22110 PCIe 4.0* x4/x2 SSD   support) (M2B_CPU)(M2C_CPU)

*Supported by   11th Generation processors only.

Chipset:

1 x M.2   connector (Socket 3, M key, type 2242/2260/2280/22110 SATA and PCIe 3.0 x4/x2   SSD support) (M2P_SB)

6 x SATA   6Gb/s connectors

Support for   RAID 0, RAID 1, RAID 5, and RAID 10

* Refer to   "1-7 Internal Connectors," for the installation notices for the M.2   and SATA connectors.

Intel®   Optane™ Memory Ready

USB

Chipset:

1 x USB   Type-C® port on the back panel, with USB 3.2 Gen 2x2 support

1 x USB   Type-C® port with USB 3.2 Gen 2 support, available through the internal USB   header

4 x USB 3.2   Gen 2 Type-A ports (red) on the back panel

2 x USB 3.2   Gen 1 ports available through the internal USB header)

Chipset+USB   3.2 Gen1 Hubs:

4 x USB 3.2   Gen1 ports on the back panel

Chipset+2 USB   2.0 Hubs:

8 x USB   2.0/1.1 ports (4 ports on the back panel, 4 ports available through the   internal USB headers)

Internal I/O   Connectors

1 x 24-pin   ATX main power connector

1 x 8-pin ATX   12V power connector

1 x 4-pin ATX   12V power connector

1 x CPU fan   header

1 x water   cooling CPU fan header

4 x system   fan headers

2 x system   fan/water cooling pump headers

2 x   addressable LED strip headers

2 x RGB LED   strip headers

6 x SATA   6Gb/s connectors

4 x M.2   Socket 3 connectors

1 x front   panel header

1 x front   panel audio header

1 x USB   Type-C® header, with USB 3.2 Gen2 support

1 x USB 3.2   Gen1 header

2 x USB   2.0/1.1 headers

2 x   Thunderbolt™ add-in card connectors

1 x Trusted   Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)

1 x Clear   CMOS jumper

2 x   temperature sensor headers

1 x Q-Flash   Plus button

＊All   fan headers are subject to support AIO_Pump, Pump and high performance fan   with the capability of delivering up to 2A/12V @ 24W.

Back Panel   Connectors

1 x USB   Type-C® port, with USB 3.2 Gen 2x2 support

4 x USB 3.2   Gen 2 Type-A ports (red)

4 x USB 3.2   Gen 1 ports

4 x USB   2.0/1.1 ports

2 x SMA   antenna connectors (2T2R)

1 x   DisplayPort

1 x RJ-45   port

1 x optical   S/PDIF Out connector

5 x audio   jacks

I/O Controller

iTE® I/O   Controller Chip

H/W   Monitoring

Voltage   detection

Temperature   detection

Fan speed   detection

Water cooling   flow rate detection

Fan fail   warning

Fan speed   control

* Whether the   fan (pump) speed control function is supported will depend on the fan (pump)   you install.

BIOS

1 x 256 Mbit   flash

Use of   licensed AMI UEFI BIOS

PnP 1.0a, DMI   2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

Unique   Features

Support for   APP Center

* Available   applications in APP Center may vary by motherboard model. Supported functions   of each application may also vary depending on motherboard specifications.

@BIOS

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

RGB Fusion

Smart Backup

System   Information Viewer

Support for   Q-Flash Plus

Support for   Q-Flash

Support for   Xpress Install

Bundled   Software

Norton®   Internet Security (OEM version)

cFosSpeed

Operating   System

Support for   Windows 10 64-bit

Form Factor

ATX Form   Factor; 30.5cm x 24.4cm
