Chipset

AMD X570

Memory

AMD Ryzen™ 5000 Series   processors:

Support for DDR4   5100(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) /   4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) /   3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933   / 2667 / 2400 / 2133 MHz memory modules

AMD Ryzen™ 4000   G-Series processors:

Support for DDR4   5400(O.C.)/ 5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) /   4300(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) /   3733(O.C.) / 3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) /   3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules

AMD Ryzen™ 3000 Series   processors:

Support for DDR4   5200(O.C.) / 5000(O.C.) / 4866(O.C.) / 4600(O.C.)/ 4400(O.C.) / 4300(O.C.) /   4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) /   3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200 / 2933   / 2667 / 2400 / 2133 MHz memory modules

AMD Ryzen™ 3000   G-Series Processors/AMD Ryzen™ 2000 Series Processors/ AMD Ryzen™ 2000   G-Series Processors:

Support for DDR4   3600(O.C.) / 3466(O.C.) / 3400(O.C.) / 3333(O.C.) / 3300(O.C.) / 3200(O.C.) /   2933 / 2667 / 2400 / 2133 MHz memory moduleses

4 x DDR4 DIMM sockets   supporting up to 128 GB (32 GB single DIMM capacity) of system memory

Dual channel memory   architecture

Support for ECC   Un-buffered DIMM 1Rx8/2Rx8 memory modules

Support for non-ECC   Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme   Memory Profile (XMP) memory modules

(Please refer "Memory   Support List" for more information.)

Audio

Realtek® ALC1220-VB   audio CODEC

* The front panel line   out jack supports DSD audio.

ESS SABRE9118 DAC chip

Support for DTS:X®   Ultra

High Definition Audio

2/4/5.1/7.1-channel

Support for S/PDIF Out

LAN

Intel® 2.5GbE LAN chip   (2.5 Gbps/1 Gbps/100 Mbps)

Wireless Communication   module

Intel® Wi-Fi 6E AX210

WIFI a, b, g, n, ac,   ax, supporting 2.4/5/6 GHz carrier frequency bands

BLUETOOTH 5.2

Support for 11ax 160MHz   wireless standard and up to 2.4 Gbps data rate

* Actual data rate may   vary depending on environment and equipment.

Expansion Slots

1 x PCI Express x16   slot (PCIEX16), integrated in the CPU:

AMDRyzen™ 5000 Series   Processors/AMDRyzen™ 3000 Series Processors support PCIe 4.0 x16 mode

AMDRyzen™   4000G-SeriesProcessors/AMDRyzen™ 2000 Series Processors support PCIe 3.0 x16   mode

AMDRyzen™   3000G-SeriesProcessors/AMDRyzen™ 2000 G-Series Processors support PCIe 3.0 x8   mode

1 x PCI Express x16   slot (PCIEX8), integrated in the CPU:

AMDRyzen™ 5000 Series   Processors/AMDRyzen™ 3000 Series Processors support PCIe 4.0 x8 mode

AMDRyzen™   4000G-SeriesProcessors/AMDRyzen™ 2000 Series Processors support PCIe 3.0 x8   mode

AMDRyzen™   3000G-SeriesProcessors/AMDRyzen™ 2000 G-Series Processors do not support this   slot

* For optimum   performance, if only one PCI Express graphics card is to be installed, be   sure to install it in the PCIEX16 slot.

* The PCIEX8 slot   shares bandwidth with the PCIEX16 slot. When the PCIEX8 slot is populated,   the PCIEX16 slot operates at up to x8 mode.

1 x PCI Express x16   slot (PCIEX4), integrated in the Chipset:

Supporting PCIe 4.0*   /3.0 x4 mode

* For AMD Ryzen™ 5000   Series Processors/AMD Ryzen™ 3000 Series Processors only.

* The PCIEX4 slot   shares bandwidth with the M2C_SB connector. The PCIEX4 slot becomes   unavailable when a device is installed in the M2C_SB connector.

Multi-Graphics   Technology

Support for AMD   Quad-GPU CrossFire™ and 2-Way AMD CrossFire™ technologies

For AMD Ryzen™ 5000   Series Processors/AMD Ryzen™ 4000 G-Series Processors/AMD Ryzen™ 3000 Series   Processors/AMD Ryzen™ 2000 Series Processors only.

Storage Interface

1 x M.2 connector   (M2A_CPU), integrated in the CPU, supporting Socket 3, M key, type   2242/2280/22110 SSDs:

AMD Ryzen™ 5000 Series   Processors/AMD Ryzen™ 3000 Series Processors support SATA and PCIe 4.0 x4/x2   SSDs

AMD Ryzen™ 4000   G-Series Processors/AMD Ryzen™ 3000 G-Series Processors/AMDRyzen™   2000SeriesProcessors/AMDRyzen™ 2000 G-Series Processors support SATA and PCIe   3.0 x4/x2 SSDs

1 x M.2 connector   (M2B_SB), integrated in the Chipset, supporting Socket 3, M key, type   2242/2280/22110 SSDs:

Supporting PCIe 4.0*   /3.0 x4/x2 SSDs

* For AMD Ryzen™ 5000   Series Processors/AMD Ryzen™ 3000 Series Processors only.

2 x M.2 connectors   (M2C_SB/M2D_SB), integrated in the Chipset, supporting Socket 3, M key, type   2242/2280/22110 SSDs:

Supporting SATA and   PCIe 4.0* /3.0 x4/x2 SSDs

* For AMD Ryzen™ 5000   Series Processors/AMD Ryzen™ 3000 Series Processors only.

6 x SATA 6Gb/s   connectors, integrated in the Chipset:

Support for RAID 0,   RAID 1, and RAID 10

* Refer to "1-9   Internal Connectors," for the installation notices for the M.2 and SATA   connectors.

USB

CPU:

2 x USB 3.2 Gen 2   Type-A ports (red) on the back panel

2 x USB 3.2 Gen 1 ports   on the back panel

Chipset+ASMedia® USB   3.2 Gen 2x2 Controller:

1 x USB Type-C® port on   the back panel, with USB 3.2 Gen 2x2 support

Chipset:

1 x USB Type-C® port   with USB 3.2 Gen 2 support, available through the internal USB header

3 x USB 3.2 Gen 2   Type-A ports (red) on the back panel

4 x USB 3.2 Gen 1   ports, available through the internal USB headers

Chipset+2 USB 2.0 Hubs:

8 x USB 2.0/1.1 ports   (4 ports on the back panel, 4 ports available through the internal USB   headers)

Internal I/O Connectors

1 x 24-pin ATX main   power connector

2 x 8-pin ATX 12V power   connectors

1 x CPU fan header

1 x water cooling CPU   fan header

4 x system fan headers

4 x system fan/water   cooling pump headers

2 x addressable LED   strip headers

2 x RGB LED strip   headers

1 x CPU cooler LED   strip/RGB LED strip header

4 x M.2 Socket 3   connectors

6 x SATA 6Gb/s   connectors

1 x front panel header

1 x front panel audio   header

1 x USB Type-C® header,   with USB 3.2 Gen 2 support

2 x USB 3.2 Gen 1   headers

2 x USB 2.0/1.1 headers

1 x noise detection   header

1 x Trusted Platform   Module (TPM) header (2x6 pin, for the GC-TPM2.0_S module only)

1 x Thunderbolt™ add-in   card connector

2 x temperature sensor   headers

1 x power button

1 x reset button

1 x Clear CMOS jumper

Voltage Measurement   Points

Back Panel Connectors

1 x Q-Flash Plus button

1 x Clear CMOS button

2 x SMA antenna   connectors (2T2R)

1 x USB Type-C® port,   with USB 3.2 Gen 2x2 support

5 x USB 3.2 Gen 2   Type-A ports (red)

2 x USB 3.2 Gen 1 ports

4 x USB 2.0/1.1 ports

1 x RJ-45 port

1 x optical S/PDIF Out   connector

5 x audio jacks

I/O Controller

iTE® I/O Controller   Chip

H/W Monitoring

Voltage detection

Temperature detection

Fan speed detection

Water cooling flow rate   detection

Overheating warning

Fan fail warning

Fan speed control

* Whether the fan   (pump) speed control function is supported will depend on the fan (pump) you   install.

Noise detection

BIOS

1 x 256 Mbit flash

Use of licensed AMI   UEFI BIOS

PnP 1.0a, DMI 2.7, WfM   2.0, SM BIOS 2.7, ACPI 5.0

Unique Features

Support for APP Center

* Available   applications in APP Center may vary by motherboard model. Supported functions   of each applicationmay also vary depending onmotherboard specifications.

@BIOS

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

RGB Fusion

Smart Backup

System Information   Viewer

Support for Q-Flash   Plus

Support for Q-Flash

Support for Xpress   Install

Bundled Software

Norton® Internet   Security (OEM version)

cFosSpeed

Operating System

Support for Windows 10   64-bit

Form Factor

ATX Form Factor; 30.5cm   x 24.4cm
