CHIPSET

 AMD A520

MEMORY

 4 x DDR4 DIMM sockets supporting up to 128   GB (32 GB single DIMM capacity) of system memory

3rd Gen AMD Ryzen™ Processors:

Support for DDR4 4000(O.C.) / 3600(O.C.) /   3333(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules

3rd Gen AMD Ryzen™ with Radeon™ Graphics   processors:

Support for DDR4 4733(O.C.) / 4600(O.C.) /   4400(O.C.) / 4000(O.C.) / 3600(O.C.) / 3333(O.C.) / 3200 / 2933 / 2667 / 2400   / 2133 MHz memory modules

Dual channel memory architecture

Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory   modules

Support for non-ECC Un-buffered DIMM   1Rx8/2Rx8/1Rx16 memory modules

Support for Extreme Memory Profile (XMP) memory   modules

ONBOARD    GRAPHICS

Integrated in the 3rd Generation AMD Ryzen™ with   Radeon™ Graphics processors:

1 x DVI-D port, supporting a maximum resolution   of 1920x1200@60 Hz

* The DVI-D port does not support D-Sub   connection by adapter.

1 x DisplayPort, supporting a maximum resolution   of 5120x2880@60 Hz

* Support for DisplayPort 1.4 version, HDCP 2.3,   and HDR.

1 x HDMI port, supporting a maximum resolution of   4096x2160@60 Hz

* Support for HDMI 2.1 version, HDCP 2.3, and   HDR.

AUDIO

 Realtek® ALC887 codec

High Definition Audio

2/4/5.1/7.1-channel

* To configure 7.1-channel audio, you need to open   the audio software and select Device advanced settings > Playback Device   to change the default setting first. Please visit GIGABYTE's website for   details on configuring the audio software.

LAN

Realtek® GbE LAN chip (1000 Mbit/100 Mbit)

WIRELESS LAN

 Intel® Wi-Fi 3168

WIFI 802.11a/b/g/n/ac, supporting 2.4/5 GHz   Dual-Band

BLUETOOTH 4.2

Support for 11ac wireless standard and up to 433   Mbps data rate

* Actual data rate may vary depending on   environment and equipment.

EXPANSION SLOTS

CPU:

1 x PCI Express x16 slot, supporting PCIe 3.0 and   running at x16

Chipset:

2 x PCI Express x1 slots, supporting PCIe 3.0   (PCIEX1_1, PCIEX1_2)

STORAGE INTERFACE

CPU:

1 x M.2 connector (Socket 3, M key, type   2242/2260/2280 SATA and PCIe 3.0 x4/x2 SSD support)

Chipset:

4 x SATA 6Gb/s connectors

Support for RAID 0, RAID 1, and RAID 10

USB

CPU:

4 x USB 3.2 Gen 1 ports on the back panel

Chipset:

2 x USB 3.2 Gen 1 ports available through the   internal USB header

4 x USB 2.0/1.1 ports (2 ports on the back panel,   2 ports available through the internal USB header)

INTERNAL I/O CONNECTOORS

 1 x 24-pin ATX main power connector

1 x 8-pin ATX 12V power connector

1 x CPU fan header

2 x system fan headers

1 x addressable LED strip header

1 x RGB LED strip header

1 x M.2 Socket 3 connector

4 x SATA 6Gb/s connectors

1 x front panel header

1 x front panel audio header

1 x USB 3.2 Gen 1 header

1 x USB 2.0/1.1 header

1 x Trusted Platform Module (TPM) header (2x6   pin, for the GC-TPM2.0_S module only)

1 x serial port header

1 x Clear CMOS jumper

1 x Q-Flash Plus button

BACK PANEL CONNECTORS

1 x PS/2 keyboard/mouse port

1 x DVI-D port

1 x DisplayPort

1 x HDMI port

2 x SMA antenna connectors (1T1R)

4 x USB 3.2 Gen 1 ports

2 x USB 2.0/1.1 ports

1 x RJ-45 port

3 x audio jacks

I/O CONTROLLER

 iTE® I/O Controller Chip

H/W MONITORING

Voltage detection

Temperature detection

Fan speed detection

Overheating warning

Fan fail warning

Fan speed control

* Whether the fan speed control function is   supported will depend on the cooler you install.

BIOS

1 x 128 Mbit flash

Use of licensed AMI UEFI BIOS

PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0

UNIQUR FEATURES

 Support for APP Center

* Available applications in APP Center may vary   by motherboard model. Supported functions of each application may also vary   depending on motherboard specifications.

@BIOS

EasyTune

Fast Boot

Game Boost

ON/OFF Charge

RGB Fusion

Smart Backup

System Information Viewer

Support for Q-Flash Plus

Support for Q-Flash

Support for Xpress Install

BUNDLED SOFTWARE

 Norton® Internet Security (OEM version)

Realtek® 8118 Gaming LAN Bandwidth Control   Utility

OS

Support for Windows 10 64-bit

FORM FACTOR

 Micro ATX Form Factor; 24.4cm x 24.4cm
