Aten USB Dual DVI Cat 5 KVM Extender (CE604)

Aten USB Dual DVI Cat 5 KVM Extender (CE604)
  • 50137_thumb_P_1552522981814
  • 50137_thumb_P_1552522994787
  • 50137_thumb_P_1552522994127
$838.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten USB Dual DVI Cat 5 KVM Extender (CE604)
  • Model Number:
    CE604-AT-U
  • Brand:
  • Manufacturer Warranty:
    2 Year

Description

Aten USB Dual DVI Cat 5 KVM Extender (CE604)


  • Local and Remote Units connect at distances up to 60 m using two Cat 5e cables

  • Supports Dual View video source transmission (one PC with two video output ports)

  • Superior video quality – up to 1920 x 1200 @ 60 Hz at 30 m; 1024 x 768 @ 60 Hz at 60 m

  • Manual compensation control to adjust video signal quality in order to compensate for distance




Specifications


FunctionCE604LCE604R
Connectors
Console PortsN/A2 x USB Type A Female (White)
2 x DVI-D Female (White)
1 x Mini Stereo Jack Female (Green)
1 x Mini Stereo Jack Female (Pink)
KVM Ports1 x USB Type B Female (White)
1 x Mini Stereo Jack Female (Green)
1 x Mini Stereo Jack Female (Pink)
2 x DVI-D Female (White)
N/A
RS-2321 x DB-9 Female (Black)1 x DB-9 Male (Black)
Power1 x DC Jack (Black)1 x DC Jack (Black)
Sub / Main2 x RJ-45 Female (Black)2 x RJ-45 Female (Black)
LEDs
Link1 (Green)1 (Green)
Power1 (Green)1 (Green)
Switches
Picture CompensationN/A2 x 8-position switch
Firmware Upgrade1 x Slide SwitchN/A
Pushbuttons
Wakeup buttonN/A1 x pushbutton
Video1920x1200 @ 60Hz (30 m); 1024x768 @ 60Hz (60 m)1920x1200 @ 60Hz (30 m); 1024x768 @ 60Hz (60 m)
Power ConsumptionDC5.3V:2.88W:18BTUDC5.3V:2.35W:15BTU
Environmental
Operating Temperature0–50°C0–50°C
Storage Temperature-20–60°C-20–60°C
Humidity0–80% RH, Non-condensing0–80% RH, Non-condensing
Physical Properties
HousingMetalMetal
Weight0.49 kg ( 1.08 lb )0.49 kg ( 1.08 lb )
Dimensions (L x W x H)20.20 x 8.53 x 2.50 cm
(7.95 x 3.36 x 0.98 in.)
20.20 x 8.67 x 2.50 cm
(7.95 x 3.41 x 0.98 in.)
NoteFor some of rack mount products, please note that the standard physical dimensions of WxDxH are expressed using a LxWxH format.


Package Contents

  • 1x CE604L (Local Unit)

  • 1x CE604R (Remote Unit)

  • 1x Custom KVM Cable (DVI-D Single Link, USB, Audio; 1.8m/6ft)

  • 1x DVI Cable (1.8m/6ft)

  • 2x Power Adapters

  • 1x Mounting Kit

  • 1x User Instructions
