CHIPSET

Intel® B460

MEMORY

2 x DIMM, Max. 64GB, DDR4 2933/2800/2666/2400/2133 MHz Non-ECC,   Un-buffered Memory *

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Profile (XMP)

OptiMem II

* 10th Gen Intel® Core™i9/i7 CPUs support 2933/2800/2666/2400/2133   natively, Refer to www.asus.com for the Memory QVL (Qualified Vendors   Lists).

GRAPHIC

Integrated Graphics Processor

1 x DisplayPort 1.4 **

1 x HDMI 1.4b

*Graphics specifications may vary between CPU types.

**Support DisplayPort 1.4 with max. resolution of 4096 x 2304 @60Hz.   Please refer to www.intel.com for any update.

EXPANSION SLOTS

Intel® 10th Gen Processors

1 x PCIe 3.0 x16

STORAGE

Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports

1 x M.2_1 socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and   SATA modes) storage devices support*2

1 x M.2_2 socket 3, with M key, type 2242/2260/2280 storage devices   support (PCIE 3.0 x 4 mode)

4 x SATA 6Gb/s port(s)

Support Raid 0, 1, 5, 10

Intel® Optane™ Memory Ready

LAN

Intel® I219-V 1Gb Ethernet

ASUS LANGuard

WIFI

Intel® Wi-Fi 6 AX200

2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) support 1024QAM/OFDMA/MU-MIMO

Supports dual band frequency 2.4/5 GHz

Supports channel bandwidth: HT20/HT40/HT80/HT160. Up to 1.73Gbps   transfer speed

Up to 2.4Gbps transfer speed

AUDIO

ROG SupremeFX 7.1 Surround Sound High Definition Audio CODEC

- Dual OP Amplifiers

- Impedance sense for front and rear headphone outputs

- Supports : Jack-detection, Multi-streaming, Front Panel   Jack-retasking

- High quality 120 dB SNR stereo playback output and 113 dB SNR   recording input

- Supports up to 32-Bit/192kHz playback

Audio Feature :

- SupremeFX Shielding™ Technology

- Rear audio USB Type-C® port

- Premium Japanese audio capacitors

- Sonic Radar III

- Sonic Studio III + Sonic Studio Virtual Mixer

* Due to limitations in HDA bandwidth, 32-Bit/192kHz is not supported   for 8-Channel audio.

USB PORTS

Rear USB Port ( Total 8 )

1 x USB 3.2 Gen 2x2 port(s)(1 x USB Type-CTM)

6 x USB 3.2 Gen 1 port(s)(4 x Type-A)

1 x USB 2.0 port(s)(1 x USB Type-C®)

Front USB Port ( Total 4 )

2 x USB 3.2 Gen 1 port(s)

2 x USB 2.0 port(s)

SOFTWARE FEATURES

[ROG Exclusive Software]

- RAMCache III

- ROG CPU-Z

- GameFirst VI

- Sonic Studio III + Sonic Studio Virtual Mixer

- Sonic Radar III

- DTS® Sound Unbound

- Overwolf

- Anti-virus software

[ASUS Exclusive Software]

Armoury Crate

- Aura Creator

- Aura Sync

AI Suite 3

- Performance And Power Saving Utility:

-TurboV EVO, EPU, Digi+ VRM, Fan Xpert 4

- EZ update

ASUS CPU-Z

DAEMON Tools

WinRAR

[UEFI BIOS]

ASUS EZ DIY

- ASUS CrashFree BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS EZ Mode

ASUS SPECIAL FEATURES

Extreme Engine Digi+

- 5K Black Metallic Capacitors

ASUS Q-Design

- ASUS Q-DIMM

- ASUS Q-LED (CPU [red], DRAM [yellow], VGA [white], Boot Device   [yellow green])

- ASUS Q-Slot

ASUS Thermal Solution

- Aluminum M.2 heatsink

ASUS EZ DIY

- BIOS FlashBack™ button

- BIOS FlashBack™ LED

- Procool

- Pre-mounted I/O shield

- SafeSlot

AURA Sync

- Standard RGB header(s)

- Addressable Gen 2 RGB header(s)

Rear audio USB Type-C® connector

BACK I/O PORTS

1 x Intel® I219-V 1Gb Ethernet

1 x DisplayPort

1 x HDMI

1 x USB 3.2 Gen 2x2 port(s) (1 x USB Type-C®)

6 x USB 3.2 Gen 1

1 x USB 2.0 *3

5 x Audio jack(s)

INTERNAL I/O PORTS

1 x CPU Fan connector(s)

1 x Chassis Fan connector(s)

1 x AIO_PUMP connector

1 x AAFP connector

1 x Aura RGB Strip Headers

1 x Addressable Gen 2 header(s)

1 x USB 3.2 Gen 1(up to 5Gbps) connector(s) support(s) additional 2   USB 3.2 Gen 1 port(s)

1 x USB 2.0 connector(s) support(s) additional 2 USB 2.0 port(s)

2 x M.2 Socket 3

1 x M.2 with E key for Wi-Fi module

1 x COM port(s) connector(s)

4 x SATA 6Gb/s connector(s)

1 x S/PDIF out header(s)

1 x 24-pin EATX Power connector(s)

1 x 8-pin ATX 12V Power connector(s)

1 x Clear CMOS jumper(s)

1 x System panel connector

ACCESSORIES

User's manual

2 x SATA 6Gb/s cable(s)

1 x pack of cable tie

1 x Supporting DVD

1 x ROG Strix stickers

1 x Extension cable for Addressable LED

1 x ROG Thank you card

1 x Wi-Fi moving antenna

1 M.2 SSD screw package(s)

1 ROG key chain

BIOS

128 Mb Flash ROM, UEFI AMI BIOS

MANAGEABILITY

 WOL by PME, PXE

OS

Windows® 10 64-bit

FORM FACTOR

Mini ITX Form Factor

6.7 inch x 6.7 inch ( 17 cm x 17 cm )
