CHIPSET

AMD X570

MEMORY

3rd Gen   AMD Ryzen™ Processors

4 x DIMM,   Max. 128GB, DDR4 MHz Un-buffered Memory

2nd Gen   AMD Ryzen™ Processors

4 x DIMM,   Max. 128GB, DDR4 MHz Un-buffered Memory

2nd and   1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors

4 x DIMM,   Max. 128GB, DDR4 MHz Memory

Dual   Channel Memory Architecture

ECC Memory   (ECC mode) support varies by CPU.

* Refer to   www.asus.com for the Memory QVL (Qualified Vendors Lists).

* The   maximum memory capacity supported vary depending on the CPU you installed.

GRAPHICS

Integrated   Graphics in the 2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics   Processors

VGA output   support : HDMI port

- Supports   HDMI 1.4b with max. resolution 4096 x 2160 @ 24 Hz

MULTI-GPU SUPPORT

3rd and   2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics   Processors

Supports   AMD 2-Way CrossFireX™ Technology

EXPANSION SLOTS

3rd Gen AMD Ryzen™ Processors

1 x PCIe 4.0 x16 (x16 mode)

2nd Gen AMD Ryzen™ Processors

1 x PCIe 3.0 x16 (x16 mode)

2nd and 1st Gen AMD Ryzen™   with Radeon™ Vega Graphics Processors

1 x PCIe 3.0 x16 (x8 mode)

AMD X570 chipset

1 x PCIe 4.0 x16 (max at x4   mode)

3 x PCIe 4.0 x1

STORAGE

3rd Gen   AMD Ryzen™ Processors :

1 x M.2_1   socket 3, with M Key, Type 2242/2260/2280 (PCIE 4.0 x4 and SATA modes)   storage devices support

2nd Gen   AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics Processors :

1 x M.2_1   socket 3, with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes)   storage devices support

AMD X570   chipset :

1 x M.2_2   socket 3, with M Key, Type 2242/2260/2280/22110(PCIE 4.0 x4 and SATA modes)   storage devices support

6 x SATA   6Gb/s port(s)

Support   Raid 0, 1, 10

LAN

Realtek® RTL8111H

ASUS LAN Guard

AUDIO

Realtek® S1200A 8-Channel High   Definition Audio CODEC *

- Supports : Jack-detection,   Front Panel Jack-retasking

- Front panel audio connector   (AAFP)

Audio Feature :

- Audio Shielding: Ensures   precision analog/digital separation and greatly reduced multi-lateral   interference

- Dedicated audio PCB layers:   Separate layers for left and right channels to guard the quality of the   sensitive audio signals

- Premium Japanese-made audio   capacitors: Provide warm, natural and immersive sound with exceptional   clarity and fidelity

* Choose the chassis with HD   audio module in front panel to support 8-channel audio output.

USB PORTS

3rd and   2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics   Processors :

2 x USB   3.2 Gen 2 port(s) (2 at back panel, teal blue, Type-A *)

3rd and   2nd Gen AMD Ryzen™/2nd and 1st Gen AMD Ryzen™ with Radeon™ Vega Graphics   Processors :

2 x USB   3.2 Gen 1 port(s) (2 at back panel, blue, Type-A)

AMD X570   chipset :

2 x USB   3.2 Gen 2 port(s) (2 at back panel, teal blue, Type-A)

AMD X570   chipset :

4 x USB   3.2 Gen 1 port(s) (4 at mid-board)

AMD X570   chipset :

5 x USB   2.0 port(s) (2 at back panel, , 3 at mid-board)

* The USB   ports under the LAN port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD   Ryzen™ Processors

SPECIAL FEATURES

ASUS 5X   Protection III :

- ASUS   SafeSlot Core: Fortified PCIe Slot prevents damage

- ASUS   LANGuard: Protects against LAN surges, lightning strikes and   static-electricity discharges!

- ASUS   Overvoltage Protection: World-class circuit-protecting power design

- ASUS   Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability!

- ASUS   DIGI+ VRM - Digital power design with Dr. MOS

- ASUS   Enhanced DRAM Overcurrent Protection - Short circuit damage prevention

- ASUS ESD   Guards - Enhanced ESD protection

ASUS   SafeSlot - Protect your graphics card Investment

ASUS   OptiMem?

- Improved   DDR4 Stability

ASUS EPU :

- EPU

AURA :

- Aura RGB   Strip Headers

- Aura   Control

-   Addressable Gen 2 Header

ASUS   Exclusive Features :

- AI Suite   3

- Ai   Charger

- Armoury   Crate

ASUS Quiet   Thermal Solution :

- Stylish   Design: MOS Heat-sink with dual thermal pads design, PCH Fan and PCH Heatsink

- ASUS Fan   Xpert 4

ASUS EZ   DIY :

- ASUS   CrashFree BIOS 3

- ASUS EZ   Flash 3

- ASUS   UEFI BIOS EZ Mode

ASUS   Q-Design :

- ASUS   Q-Slot

- ASUS   Q-DIMM

BACK I/O PORTS

1 x PS/2 keyboard/mouse combo   port(s)

1 x HDMI

1 x LAN (RJ45) port(s)

2 x USB 2.0

3 x Audio jack(s)

2 x USB 3.2 Gen 1 (up to 5Gbps)   ports Type-A

4 x USB 3.2 Gen 2 (up to   10Gbps) ports (Type-A *)

* The USB ports under the LAN   port can run at USB 3.2 Gen 2 speeds with 3rd Gen AMD Ryzen™ Processors

INTERNAL I/O PORTS

2 x Aura RGB Strip Headers

1 x Addressable Gen 2 header(s)

2 x USB 2.0 connector(s)   support(s) additional 5 USB 2.0 port(s)

1 x M.2 Socket 3 with M Key,   type 2242/2260/2280/22110 storage devices support (SATA mode & X4 PCIE   mode)

1 x M.2 Socket 3 with M Key,   type 2242/2260/2280 storage devices support (SATA mode & X4 PCIE mode)

1 x SPI TPM header

1 x COM port(s) connector(s)

6 x SATA 6Gb/s connector(s)

1 x CPU Fan connector(s) (1 x 4   -pin)

3 x Chassis Fan connector(s) (3   x 4 -pin)

1 x PCH_FAN (1 x 4 -pin)

1 x AIO_PUMP connector (1 x 4   -pin)

1 x S/PDIF out header(s)

1 x 24-pin EATX Power   connector(s)

1 x 8-pin ATX 12V Power   connector(s)

1 x 4-pin ATX 12V Power   connector(s)

1 x Front panel audio   connector(s) (AAFP)

1 x System panel(s)

1 x Clear CMOS jumper(s)

2 x USB 3.2 Gen 1 (up to 5Gbps)   connector support additional 2 USB ports

ACCESSORIES

User's manual

I/O Shield

2 x SATA 6Gb/s cable(s)

1 x M.2 Screw Package

1 x Supporting DVD

1 x Extension cable for   Addressable LED

BIOS

256 Mb Flash ROM, UEFI AMI   BIOS, PnP, SM BIOS 3.2, ACPI 6.2, Multi-language BIOS, ASUS EZ Flash 3,   CrashFree BIOS 3, F6 Qfan Control, F3 My Favorites, Last Modified log, F12   PrintScreen, F4 AURA ON/OFF, F9 Search and ASUS DRAM SPD (Serial Presence   Detect) memory information

MANAGEABILITY

WOL by PME, PXE

OPERATING   SYSTEM

Windows® 10 64-bit

FORM   FACTOR

ATX Form Factor

12 inch x 9.6 inch ( 30.5 cm x   24.4 cm )
