CHIPSET

 Intel® H470

MEMORY

 4 x DIMM, Max. 128GB, DDR4   2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory *

Dual Channel Memory Architecture

Supports Intel® Extreme Memory Profile (XMP)

OptiMem

GRAPHIC

 Integrated Graphics Processor

1 x DisplayPort 1.4 **

1 x HDMI 1.4b

1 x DVI-D

*Graphics specifications may vary between CPU   types.

MULTI GPU SUPPORT

 Supports   AMD 2-Way CrossFireX Technology

EXPANSION SLOTS

 Intel® 10th   Gen Processors

1 x PCIe 3.0 x16   (x16 mode)

Intel® H470   Chipset

1 x PCIe 3.0 x16   (x4 mode)

2 x PCIe 3.0 x1

STORAGE

 Total   supports 2 x M.2 slots and 5 x SATA 6Gb/s ports

Intel® H470   Chipset :

1 x M.2 Socket 3,   with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4   mode)

1 x M.2 Socket 3,   with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0   x 4 mode)*1

5 x SATA 6Gb/s   port(s)

Support Raid 0,   1, 5, 10

Intel® Rapid   Storage Technology supports

Intel® Optane™   Memory Ready

LAN

 Intel®   I219-V 1Gb Ethernet

WIFI

BLUETOOTH

AUDIO

 Realtek®   ALC887 8-Channel High Definition Audio CODEC

- Supports :   Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to   24-Bit/192kHz playback

Audio Feature :

- LED-illuminated   design

- Audio Shielding

- Dedicated audio   PCB layers

- Premium   Japanese audio capacitors

USB PORTS

 Rear USB   Port ( Total 6 )

2 x USB 3.2 Gen 2   port(s)(1 x Type-A +1 x USB Type-C®)

2 x USB 3.2 Gen 1   port(s)(2 x Type-A)

2 x USB 2.0   port(s)(2 x Type-A)

Front USB Port (   Total 8 )

4 x USB 3.2 Gen 1   port(s)

4 x USB 2.0   port(s)

SOFTWARE FEATURES

 ASUS   Exclusive Software

Armoury Crate

AI Suite 3

- Performance And   Power Saving Utility

EPU

Digi+ VRM

Fan Xpert 4

- EZ update

AI Charger

WinRAR

UEFI BIOS

ASUS EZ DIY

- ASUS CrashFree   BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS   EZ Mode

ASUS SPL FEATURES

 ASUS 5X   PROTECTION III

- ASUS DIGI+ VRM   (- Digital power design with Dr. MOS)

- ASUS LANGuard

- ASUS   Overvoltage Protection

- ASUS SafeSlot   Core+

- ASUS   Stainless-Steel Back I/O

ASUS Q-Design

- ASUS Q-DIMM

- ASUS Q-Slot

ASUS Thermal   Solution

- Aluminum   heatsink design

ASUS EZ DIY

- Procool

BACK I/O PORTS

 1 x PS/2   keyboard/mouse combo port(s)

1 x DVI-D

1 x DisplayPort

1 x HDMI

1 x LAN (RJ45)   port(s)

2 x USB 3.2 Gen 2   (1 x Type-A+1 x USB Type-C®)

2 x USB 3.2 Gen 1   Type-A

2 x USB 2.0

3 x Audio jack(s)

IN TERNAL I/O   PORTS

 1 x CPU Fan   connector(s)

3 x Chassis Fan   connector(s)

1 x AIO_PUMP   connector

1 x Lighting   Control RGB Strip Header(s)

2 x USB 3.2 Gen   1(up to 5Gbps) connector(s) support(s) additional 4 USB 3.2 Gen 1 port(s)

2 x USB 2.0   connector(s) support(s) additional 4 USB 2.0 port(s)

1 x M.2 Socket 3   with M key, type 2242/2260/2280/22110 storage devices support (PCIE 3.0 x 4   mode)

1 x M.2 Socket 3   with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0   x 4 mode)

1 x SPI TPM   header

5 x SATA 6Gb/s   connector(s)

1 x S/PDIF out   header(s)

1 x 4-pin EATX 12   V Power connector

1 x 24-pin EATX   Power connector(s)

1 x 8-pin EATX 12V   Power connectors

1 x Front panel   audio connector(s) (AAFP)

1 x Clear CMOS   jumper(s)

1 x System panel   connector

1 x COM port   header

ACCESSORIES

 I/O Shield

2 x SATA 6Gb/s   cable(s)

1 x M.2 Screw   Package

1 x Supporting   DVD

User manual

BIOS

 128 Mb   Flash ROM, UEFI AMI BIOS

MANAGEABILITY

 WOL by PME,   PXE

OS

 Windows® 10   64-bit

FORM FACTOR

 mATX Form   Factor

9.6 inch x 9.6   inch ( 24.4 cm x 24.4 cm )
