Chipset

Intel® B560   Chipset

Memory

5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC)/3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133   MHz Non-ECC, Un-buffered Memory*

Dual Channel   Memory Architecture

Supports   Intel® Extreme Memory Profile (XMP)

OptiMem II

* 10th Gen   Intel® Core™ i7/i9 processors support 2933/2800/2666/2400/2133 natively,   others will run at the maximum transfer rate of DDR4 2666MHz.

* 11th Gen   Intel® processors support 3200/2933/2800/2666/2400/2133 natively.

* Refer to   www.asus.com for the Memory QVL (Qualified Vendors Lists), and memory   frequency support depends on the CPU types.

Graphics

1 x   DisplayPort 1.4

2 x HDMI™   2.0**

* Graphics   specifications may vary between CPU types.

** Intel®   11th & 10th Gen processors support DisplayPort 1.4 with max. resolution   of 4096 x 2304 @60Hz. Please refer to www.intel.com for any updates.

*** Only   Intel® 11th Gen processors support HDMI™ 2.0 with max. resolution of 4K@60Hz,   others will only support HDMI™ 1.4 with max. resolution of 4K@30Hz .Please   refer to www.intel.com for any updates.

Expansion   Slots

Intel® 11th   &10th Gen Processors

1 x PCIe   4.0/3.0 x16 slot(s)*

- Intel® 11th   Gen processors support PCIe 4.0 x16

- Intel®10th   Gen processors support PCIe 3.0 x16

Intel® B560   Chipset

1 x PCIe 3.0   x16 slot (supports x4 mode)*

1 x PCIe 3.0   x1 slots

* Enable RST   PCIe Storage Remapping for PCH attached PCIe slots to activate Intel® Optane   Memory.

Storage

Intel®11th   Gen Processors

M.2_1 slot   (Key M), type 2242/2260/2280

- Only Intel®   11th Gen processors support PCIe 4.0 x4 mode, this slot will be disabled for   other CPUs

Intel® B560   Chipset

M.2_2 slot   (Key M), type 2242/2260/2280 (supports PCIe 3.0 x4 & SATA modes)*

6 x SATA   6Gb/s ports

* M.2_2 slot   shares bandwidth with SATA_2.When M.2_2 slot is operating in SATA mode,   SATA_2 will be disabled.

Ethernet

1 x Intel®   I219-V 1Gb Ethernet

ASUS LANGuard

Wireless   & Bluetooth

V-M.2 slot   only (Key E, CNVi & PCIe)*

* Wi-Fi   module and vertical M.2 Key E bracket set are purchased separately.

USB

Rear   USB:Total 6 ports

2 x USB 3.2   Gen 2 port(s) (1 x Type-A + 1 x USB Type-C®)

4 x USB 2.0   port(s) (4 x Type-A)

Front   USB:Total 7 ports

2 x USB 3.2   Gen 1 header(s) support(s) additional 4 USB 3.2 Gen 1 ports

1 x USB 2.0   header(s) support(s) additional 2 USB 2.0 ports

1 x USB 2.0   header(s) support(s) additional 1 USB 2.0 ports

Audio

- Supports:   Jack-detection, Multi-streaming, Front Panel Jack-retasking

- Supports up   to 24-Bit/192 kHz playback"

Audio   Features

- Audio   Shielding

- Premium   Japanese audio capacitors

- Dedicated   audio PCB layers

** A chassis   with an HD audio module in the front panel is required to support 7.1   Surround Sound audio output.

Back Panel   I/O Ports

2 x USB 3.2   Gen 2 port(s) (1 x Type-A, 1 x USB Type-C®)

4 x USB 2.0   port(s) (4 x Type-A)

1 x   DisplayPort

2 x HDMI™   port

1 x Intel®   I219-V 1Gb Ethernet port

1 x V-M.2   slot (Key E)

3 x Audio   jacks

1 x PS/2   Keyboard/Mouse combo port

Internal   I/O Connectors

Fan and   Cooling related

1 x 4-pin CPU   Fan header(s)

1 x 4-pin CPU   OPT Fan header(s)

2 x 4-pin   Chassis Fan header(s)

Power related

1 x 24-pin   Main Power connector

1 x 8-pin   +12V Power connector

Storage   related

2 x M.2 slots   (Key M)

6 x SATA   6Gb/s ports

USB

2 x USB 3.2   Gen 1 header(s) support(s) additional 4 USB 3.2 Gen1 ports

1 x USB 2.0   header(s) support(s) additional 2 USB 2.0 ports

1 x USB 2.0   header(s) support(s) additional 1 USB 2.0 ports

Miscellaneous

2 x AURA   Addressable Gen 2 header(s)

2 x AURA RGB   header(s)

1 x Clear   CMOS header

1 x COM Port   header

1 x Front   Panel Audio header (AAFP)

1 x LPT   header

1 x S/PDIF   Out header

1 x SPI TPM   header (14-1pin)

1 x 20-3 pin   System Panel header with Chassis intrude function

Special   Features

ASUS 5X   PROTECTION III

- DIGI+ VRM

- Enhanced   DRAM Overcurrent Protection

- ESD Guards

- LANGuard

- Overvoltage   Protection

- SafeSlot   Core+

-   Stainless-Steel Back I/O

ASUS Q-Design

- Q-DIMM

- Q-LED (CPU   [red], DRAM [yellow], VGA [white], Boot Device [yellow green])

- Q-Slot

ASUS Thermal   Solution

- Flexible   M.2 heatsink

- VRM   heatsink design

AURA Sync

- AURA RGB   header(s)

- Addressable   Gen 2 RGB header(s)

Software   Features

ASUS   Exclusive Software

Armoury Crate

- AURA   Creator

- AURA Sync

AI Suite 3

- Performance   And Power Saving Utility

TurboV EVO

EPU

Digi+ VRM

Fan Xpert 2+

- EZ update

ASUS CPU-Z

AI Charger

DAEMON Tools

Norton   Anti-virus software (Free Trial version)

WinRAR

UEFI BIOS

ASUS EZ DIY

- ASUS   CrashFree BIOS 3

- ASUS EZ   Flash 3

- ASUS UEFI   BIOS EZ Mode

BIOS

128 Mb Flash   ROM, UEFI AMI BIOS

Manageability

WOL by PME,   PXE

Accessories

Cables

2 x SATA   6Gb/s cables

Miscellaneous

1 x M.2   Rubber Package(s)

1 x M.2 SSD   screw package(s)

1 x Vertical   M.2 Key E bracket set

1 x ACC   Express Activation Key Card

Installation   Media

1 x Support   DVD

Documentation

1 x User   manual

Operating   System

Windows® 10   64-bit

Form   Factor

microATX

24.4cm x   23.4cm
