CHIPSET

AMD A520

MEMORY

 2 x DIMM, Max. 64GB, DDR4   4600(O.C)/4400(O.C)/4000(O.C.)/3866(O.C.)/

3733(O.C.)/3600(O.C.)/3466(O.C.)/3333(O.C.)/3200/

3000/2800/2666/2400/2133 MHz Un-buffered Memory *

Dual Channel Memory Architecture

ECC Memory (ECC mode) support varies by CPU.

GRAPHIC

1  x D-Sub

1  x HDMI   2.1(4K@60HZ)

MULTI GPU SUPPORT

EXPANSION SLOTS

 AMD Ryzen™   5000 Series/ 4000 G-Series/ 3000 Series Desktop Processors

1 x PCIe 3.0 x16   (x16 mode)

AMD A520 Chipset

2 x PCIe 3.0 x1

STORAGE

Total supports 1   x M.2 slot(s) and 4 x SATA 6Gb/s ports

AMD Ryzen™ 5000   Series/ 4000 G-Series/ 3000 Series Desktop Processors :

1 x M.2 Socket 3,   with M Key, Type 2242/2260/2280 (PCIE 3.0 x4 and SATA modes) storage devices   support

AMD A520 Chipset   :

4 x SATA 6Gb/s   port(s),

Support Raid 0,   1, 10

LAN

 Realtek   RTL8111H 1Gb Ethernet

ASUS LANGuard

WIFI

BLUETOOTH

AUDIO

 Realtek   ALC887/897 7.1 Surround Sound High Definition Audio CODEC *

- Supports :   Jack-detection, Multi-streaming, Front Panel Jack-retasking, up to   24-Bit/192kHz playback

Audio Feature :

- Audio Shielding

- Dedicated audio   PCB layers

* Choose the   chassis with HD audio module in front panel to support 8-channel audio   output.

USB PORTS

 Rear USB   Port ( Total 6  )

4 x USB 3.2 Gen 1   port(s)(4 x Type-A)

2 x USB 2.0   port(s)(2 x Type-A)

Front USB Port (   Total 6  )

2 x USB 3.2 Gen 1   port(s)(2 x Type-A)

4 x USB 2.0   port(s)(4 x Type-A)

SOFTWARE FEATURES

 ASUS   Exclusive Software

Armoury Crate

AI Suite 3

- Performance and   Power Saving Utility

TurboV EVO

EPU

Digi+ VRM

Fan Xpert

- EZ update

ASUS CPU-Z

AI Charger

DAEMON Tools

Norton Anti-virus   software (Free Trial for 60 days)

WinRAR

UEFI BIOS

ASUS EZ DIY

- ASUS CrashFree   BIOS 3

- ASUS EZ Flash 3

- ASUS UEFI BIOS   EZ Mode

ASUS SPL FEATURES

 ASUS 5X   PROTECTION III

- ASUS DIGI+ VRM

- ASUS LANGuard

- ASUS   Overvoltage Protection

- ASUS SafeSlot   Core

- ASUS   Stainless-Steel Back I/O

ASUS Q-Design

- ASUS Q-DIMM

- ASUS Q-Slot

ASUS Thermal Solution

- Aluminum   heatsink design

BACK I/O PORTS

 1 x PS/2   keyboard/mouse combo port(s)

1 x D-Sub

1 x HDMI

1 x LAN (RJ45)   port(s)

4 x USB 3.2 Gen 1   (blue) Type-A

2 x USB 2.0

3 x Audio jack(s)

IN TERNAL I/O   PORTS

1 x CPU Fan connector(s)

1 x Chassis Fan   connector(s)

1 x USB 3.2 Gen   1(up to 5Gbps) connector(s) support(s) additional 2 USB 3.2 Gen 1 port(s)

2 x USB 2.0   connector(s) support(s) additional 4 USB 2.0 port(s)

1 x M.2 Socket 3   with M key, type 2242/2260/2280 storage devices support (SATA & PCIE 3.0   x 4 mode)

1 x SPI TPM   header

4 x SATA 6Gb/s   connector(s)

1 x S/PDIF out   header(s)

1 x 24-pin EATX   Power connector(s)

1 x 8-pin EATX   12V Power connectors

1 x Front panel   audio connector(s) (AAFP)

1 x Clear CMOS   jumper(s)

1 x System panel   connector

1 x COM port   header

1 x Speaker   connector

ACCESSORIES

User´s manual

1 x ACC Express   Activation Key Card

I/O Shield

2 x SATA 6Gb/s   cable(s)

1 x Supporting   DVD

1 x M.2 SSD screw   package(s)

BIOS

 256 Mb   Flash ROM, UEFI AMI BIOS

MANAGEABILITY

 WOL by PME,   PXE

OS

 Windows® 10   64-bit

FORM FACTOR

 mATX Form   Factor

8.9  inch x 8.7    inch ( 22.6  cm x 22.1  cm )
