APC- SCHNEIDER SMART-UPS X 750VA RACK/TOWER LCD 230V

APC- SCHNEIDER SMART-UPS X 750VA RACK/TOWER LCD 230V
  • 29586
$577.5
Was: $776.0  WAS Tips    Save $198.5
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    APC- SCHNEIDER SMART-UPS X 750VA RACK/TOWER LCD 230V
  • Model Number:
    SMX750I
  • Brand:
  • Manufacturer Warranty:
    1 Year

Description


APC Smart-UPS,600 Watts /750 VA,Input 230V /Output 230V, Interface Port SmartSlot, USB, Extended runtime model, Rack Height 2 U



IncludesCD with software, Documentation CD, Installation guide, Rack Mounting brackets, Removable support feet, Smart UPS signalling RS-232 cable, User Manual
Output Output Power Capacity 600 Watts / 750 VA
Max Configurable Power 600 Watts / 750 VA
Nominal Output Voltage 230V
Output Voltage Distortion Less than 5%
Output Frequency (sync to mains) 50/60Hz +/- 3 Hz
Topology Line Interactive
Waveform Type Sine wave
Output Connections
(8) IEC 320 C13
(2) IEC Jumpers
Input Nominal Input Voltage 230V
Input Frequency 50/60 Hz +/- 3 Hz (auto sensing)
Input Connections
IEC-320 C14
Cord Length 1.83 meters
Input voltage range for main operations 160 - 286V
Input voltage adjustable range for mains operation 151 - 302V
Other Input Voltages 220, 240
Batteries & Runtime Battery Type Maintenance-free sealed Lead-Acid battery with suspended electrolyte : leakproof
Included Battery Modules 1
Available Battery Module Slots 1
Typical recharge time 3 hour(s)
Replacement Battery APCRBC116
RBC Quantity 1
DC Overcurrent Protection 60A
Extended Run Options APC Smart-UPS X 750VA Rack/Tower LCD 230V
Energy Use/Efficiency Load Efficiency
25% 93.1%
50% 96.2%
75% 97.3%
100% 97.7%
Communications & Management Interface Port(s) SmartSlot, USB
Available SmartSlot Interface Quantity 1
Control panel Multi-function LCD status and control console
Audible Alarm Alarm when on battery : distinctive low battery alarm : overload continuous tone alarm
Surge Protection and Filtering Surge energy rating 645 Joules
Filtering Full time multi-pole noise filtering : 5% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical Maximum Height 89.00 mm
Maximum Width 432.00 mm
Maximum Depth 490.00 mm
Rack Height 2U
Net Weight 22.05 KG
Shipping Weight 26.50 KG
Shipping Height 246.00 mm
Shipping Width 589.00 mm
Shipping Depth 620.00 mm
Color Black
Units per Pallet 8.00
Environmental Operating Environment 0 - 40 °C
Operating Relative Humidity 0 - 95%
Operating Elevation 0-3000 meters
Storage Temperature -15 - 45 °C
Storage Relative Humidity 0 - 95%
Storage Elevation 0-15000 meters
Audible noise at 1 meter from surface of unit 40.00 dBA
Online Thermal Dissipation 69.00 BTU/hr
Conformance Regulatory Approvals C-tick, CE, EN 50091-1, EN 50091-2, VDE
Standard Warranty 3 years repair or replace (excluding battery) and 2 year for battery
Sustainable Offer Status RoHS Compliant
REACH REACH: Contains No SVHCs
PEP Available in Documentation tab
EOLI Available in Documentation tab
Note *Except where noted, all prices are Estimated Resale Price (ERP) - With Tax/VAT. Pricing in other locations and sites may vary.
**The time to recharge to 90% of full battery capacity following a discharge to shutdown using a load rated for 1/2 the full load rating of the UPS.

* Specifications are subject to change without notice.
* Specifications may vary.
* The product picture(s) is only for your reference, it may differ from the actual product.
