CPU: Intel® Celeron™ Processor J1900 Quad Core 2.0 GHz SoC
BIOS: AMI uEFI 64Mbit
Technology: DDR3L 1333 MHz
Socket: 2 x 204-pin SO-DIMM
Max. Capacity: 8GB (up to 4GB per SO-DIMM)
Processor Graphics: Intel® HD Graphics
Max. Resolution: VGA: 2048 x 1280 @ 60Hz;HDMI: 1920 x 1080 @ 60Hz;DP++: 1920 x 1080 @ 60Hz
Output: Dual Display
Graphic Engine: DirectX 11.1, OGL 3.0, OCL 1.1, OGL ES 2.0;Encode: H.264, MPEG2/4, VC1, WMV9;Decode: H.264, MPEG2
Others: mSATA via MiniPCIe slot
SATA: 1 x 2.5-inch SATA II HDD/SSD (only support 7 mm height)
Interface: Gigabit LAN Controller
Controller: 2 x Intel I211
HDMI: 1
DP++: 1
VGA: 1
LAN: 2
USB2.0: 3
USB3.0: 1
Audio: 1 x Mic-in, 1 x SPDIF/Line-Out(support jack-sense via OS setting)
Serial port: 2 x RS-232
Mini-PCIe (Internal): 2 x Full-size Mini PCIe
SIM Socke: 1 x SIM card size (Optional)
Power input: 1 (DC-in Jack)
Management: ACPI 3.0
Power Consumption Input Voltage: Idle Mode: 4.39W (w/o expansion) Full Mode:10.85W (w/o expansion)
Input Voltage: 19V DC-in (ATX/AT mode, default ATX)
Others: Supports Boot on Power back and schedule boot up function
Output: Interrupt, system reset
Interval: Programmable by SUSIAccess
Mounting: Supports VESA/DIN Rail/Wall Mounting (Optional)
Dimensions(W x D x H): 204x 118.2 x 44.2 mm
Weight: 1.1 kg
Operating Temperature: 0 ~ 40° C (32 ~ 104° F) (w / HDD)
Relative Humidity: 95% @ 40° C (non-condensing)
Linux: Linux Fedora 20
Microsoft Windows: WES7E, Windows 7, WE8S, Windows 8
EMC: CE, FCC Class B, CCC, BSMI
Safety Certifications: UL, CB, CCC, BSMI
