Dimensions

30.0 mm x 22.0 mm x 2.38 mm (1.18" x 0.87" x 0.09")

Weight

4 g (0.14 oz)

Bus Interface

NVMe PCIe Gen4 x4

Flash Type

3D NAND flash

Capacity

1TB

Operating Temperature

0°C (32°F) ~ 70°C (158°F)

Operating Voltage

3.3V±5%

Sequential Read/Write (CrystalDiskMark)

Up to 5,000/3,500 MB/s

4K Random Read/Write (IOmeter)

Up to 330,000/690,000 IOPS

Terabytes Written (TBW)

600 TBW

Mean Time Between Failures (MTBF)

2,000,000 hour(s)

Drive Writes Per Day (DWPD)

0.33 (5 yrs)

Certificate

CE/UKCA/FCC/BSMI/KC/RCM

Operating System

Microsoft Windows 7 or later

Linux Kernel 2.6.31 or later

Technology

S.M.A.R.T.

Advanced Garbage Collection

LDPC Coding

Note

• Speed may vary due to host hardware, software, usage, and storage capacity.
• The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
• Terabytes Written (TBW) expresses the endurance under the highest capacity.
• Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
• Speed may vary due to host hardware, software, usage, and storage capacity.
• The workload used to rate DWPD may be different from your actual workload, which may vary due to host hardware, software, usage, and storage capacity.
• Terabytes Written (TBW) expresses the endurance under the highest capacity.
• Some motherboards only provide PCIe x2 connections for the M.2 slot, creating a bottleneck on even the fastest drives.
