Interface

1 x 10M/100M/1000M/2.5Gbps Ethernet Port (RJ45)

Button

Reset

Power Supply

802.3at PoE

Max. Power Consumption

18.4W (for PoE+)

Dimensions ( W x D x H )

8.19 x 6.3 x 2.17 in (208 × 160 × 55 mm)

Antenna

• 2.4 GHz:

2 × 4.5 dBi, external omnidirectional antennas

2 × 8.3 dBi, internal directional antennas (antenna beamwidth 90°)

• 5 GHz:

2 × 5.3 dBi, external omnidirectional antennas

2 × 13.2 dBi, internal directional antennas (antenna beamwidth 45°)

Note: The gains above are the single-antenna peak gains.

Bluetooth

BLE 5.2

Weatherproof Enclosure

IP66

Mounting

Pole/Wall Mounting (Kits included)

WIRELESS FEATURES

Wireless Standards

IEEE 802.11a/g/b/n/ac/ax/be

Frequency

2.4 GHz, 5 GHz

Signal Rate

688 Mbps (2.4 GHz) + 2882 Mbps (5 GHz)

Wireless Functions

• 4k-QAM

• OFDMA

• Multiple SSIDs: 16 (8 for each band)

• Enable/Disable Wireless Radio

• Automatic Channel Assignment

• Transmit Power Control (Adjust Transmit Power on dBm)

• QoS (WMM)

• MLO

• Omada Mesh*

• Seamless Roaming(802.11k/v/r)*

• Band Steering

• Load Balance

• Airtime Fairness

• Beamforming

• Rate Limit

• Reboot Schedule

• Wireless Schedule

• Wireless Statistics based on SSID/AP/Client

• Static IP/Dynamic lP

* Coverage is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.

Wireless Security

• Captive Portal Authentication*

• Access Control

• Wireless Mac Address Filtering

• Wireless Isolation Between Clients

• SSID to VLAN Mapping

• Rogue AP Detection

• 802.1X Support

• WPA-Personal/Enterprise, WPA2-Personal/Enterprise, WPA3-Personal/Enterprise, OWE

* Coverage is calculated based on laboratory testing. Actual coverage is not guaranteed and will vary as a result of client limitations and environmental factors.

Transmission Power

• CE: (EIRP)

2.4 GHz: 20 dBm

5 GHz: 23 dBm in U-NII-1, 23 dBm in U-NII-2A, 30 dBm in U-NII-2C

• FCC: (Conducted Power)

2.4 GHz: 25 dBm

5 GHz: 26 dBm in U-NII-1, 24 dBm in U-NII-2A, 24 dBm in U-NII-2C, 26 dBm in U-NII-3

MANAGEMENT FEATURES

Omada App

Yes

Centralized Management

• Omada Cloud-Based Controller

• Omada Hardware Controller

• Omada Software Controller

Cloud Access

Yes. Require the use of an Omada controller.

Email Alerts

Yes

Management MAC Access Control

Yes

SNMP

v1, v2c, v3

System Logging Local/Remote Syslog

Yes

SSH

Yes

Web-based Management

Yes

L3 Management

Yes

Multi-site Management

Yes

Management VLAN

Yes

Zero-Touch Provisioning

Yes. Requiring the use of Omada Cloud-Based Controller

OTHERS

Certification

CE, FCC, RoHS, IC, NCC, VCCI, JRF, BSMI

Package Content

• Access Point EAP725-Outdoor

• Waterproof Kit

• Mounting Kit

• Installation Guide

System Requirements

Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux

Environment

• Operating Temperature: -30 to 70 ℃ (-22 to 158 ℉)

• Storage Temperature: -40 to 70 ℃ (-40 to 158 ℉)

• Operating Humidity: 10 to 90% RH non-condensing

• Storage Humidity: 5 to 90% RH non-condensing

Weight

Main Unit: 1.33 kg
