Image Sensor

1/2.65” Progressive Scan CMOS

Shutter Speed

1/3 to 1/10000 s

Slow Shutter

Yes

Minimum Illumination

0.005 Lux; 0 Lux with IR/White light

Day/Night Mechanism

IR Cut Filter

Day/Night Switch

Auto

LENS

Type

Fixed Focal Lens

Focal Length

4 mm

Aperture

F1.6

FOV

4 mm:

Horizontal FOV: 92°, Vertical FOV: 48°, Diagonal FOV: 110°

Lens Mount

M12*P 0.5

DORI Distance

4 mm

Detect: 262 ft (80 m)

Observe: 108 ft (33 m)

Recognize: 52 ft (16 m)

Identify: 26 ft (8 m)

ANGLE ADJUSTMENT (MANUAL)

Range

Pan: 0° to 360°, Tilt: 0° to 85°, Rotation: 0° to 360°

ILLUMINATOR

Illuminator On/Off Control

Auto/Always on/Always off

Integrated Infrared-White LED

• Quantity: 2

• IR Range: 98 ft (30 m)

• White LED Range: 98 ft (30 m)

• IR Wavelength: 850 nm

VIDEO

Max. Resolution

2880x1620

Main Stream

• Frame Rate:

50Hz: 25fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720)

60Hz: 30fps (2880x1620, 2688x1520, 2304x1296, 2048x1280, 1920x1080, 1280x720)

Sub-Stream

• Frame Rate:

50Hz: 25fps (848x480,704x576, 640x480, 640x360,352x288, 320x240)

60Hz: 30fps (848x480,704x576, 640x480, 640x360,352x288, 320x240)

Bit Rate Control

CBR, VBR

Video Compression

• Main Stream: H.265+/H.265/H.264+/H.264

• Sub-Stream: H.265/H.264

H.264 Type

High Profile

H.264+

Main Stream Supported

H.265 Type

Main Profile

H.265+

Main Stream Supported

Video Bit Rate

• Main Stream: 256 Kbps to 6144 Kbps

• Sub-Stream: 64 Kbps to 512 Kbps


Image Settings

• Mirror

• Brightness

• Contrast

• Saturation

• Sharpness

• Exposure

• WDR

• White Balance

Image Enhancement

BLC/3D DNR/SmartIR

Wide Dynamic Range

120dB

SNR

≥ 52 dB

Image Parameters Switch

Yes

Privacy Mask

Up to 4 Masks

OSD Setting

Yes

AUDIO

Audio Communication

N/A

Audio Input

Yes (Built-in Microphone)

Audio Output

N/A

Audio Compression

Yes

Audio Sampling Rate

8KHz, 16KHz

Environment Noise Filtering

Yes

Audio Bit Rate

64 Kbps(G.711 alaw, G.711 ulaw)

NETWORK

Protocol

TCP/IP, UDP, ICMP, ARP, SNMP, SMTP, RTMP, HTTP, HTTPS, DHCP, DNS, RTSP, RTP, NTP, IPv4, IPv6, UPnP, SSL/TLS, FTP/SFTP

ONVIF

Yes

API

Open Network Video Interface (Profile S/T)

Simultaneous Live View

3 Main Streams & 3 Sub-Streams

Client

Web UI, Omada Guard APP, Omada Cloud-Based Controller (Guard)

Web Browser

• Google Chrome® 57 and above

• Firefox® 52 and above

• Safari® 11 and above

• Microsoft® Edge 91 and above

Cloud

Yes

Security

Password Protection, HTTPS Encryption, IP/MAC Restriction, Digest Authentication, 802.1X authentication

ALARM AND EVENT MANAGEMENT

Event

• Motion Detection (People Detection, Vehicle Detection, Pet Detection)

• Intrusion Detection

• Line-Crossing Detection

• Video Tampering Detection

Alarm Linkage

• Sending Email

• Upload to FTP

• Message Push

INTERFACES

Network Interface

1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE

Alarm

N/A

Reset Button

N/A

Power

DC Power Port

On-board Storage

N/A

Built-in Microphone

Yes; Records Anything Going on within a 16.4-ft (5 m) Radius of the Camera

Built-in Speaker

N/A

Audio

N/A

GENERAL

Operating Temperature

-30 °C to 60 °C (-22 °F to 140 °F)

Storage Temperature

-40 °C to 60 °C (-40 °F to 140 °F)

Operating Humidity

95% or Less (Non-Condensing)

Storage Humidity

95% or Less (Non-Condensing)

Package Content

• Omada Camera

• Quick Start Guide

• Waterproof Accessories

• Mounting Accessories

• Network Cable

• Surveillance Sticker

• Mounting Templates

• Installation Guide

Material

Metal

Net Weight

0.45 kg

Power Supply

DC

• 12V DC ± 5%, Max. 7.4 W, 5.5 mm Coaxial Power Plug

• Recommended Power Supply: T120100-2C1 (for EU Regions)

PoE

• PoE: 802.3af/at, Max. 8.7 W

ErP Information

• Power consumption in networked standby when all wired network ports are   connected and all wireless network ports are activated: 2.2 W

Protection

IP67 Weatherproof, IK08 Vandal Proof

Product Dimensions (L x W x H)

4.4 × 4.4 × 3.4 in (112 × 112 × 87 mm)

Certifications

CE, FCC, BSMI, VCCI, KC, NTRA, IP67, IK08
