SPECIFICATIONS:
HARDWARE FEATURES | Interface | 1× 10/100 Mbps LAN/WAN Port, 2× 10/100 Mbps LAN Ports, 1× Phone Port, 1 Nano SIM Card Slot | Button | WPS/RESET Button, Wi-Fi ON/OFF Button | External Power Supply | 12V/1A | Dimensions ( W x D x H ) | 7.95 × 5.55 × 1.32 in (202 × 141 × 33.6 mm) | Antenna | 2× Detachable External 4G LTE Antennas | WIRELESS FEATURES | Wireless Standards | IEEE 802.11b, 802.11g, 802.11n | Frequency | 2.4 GHz | Signal Rate | 300Mbps at 2.4GHz | Reception Sensitivity | 11g 54M: -74 dBm
11n HT20: -71 dBm
11n HT40: -67 dBm | Wireless Functions | Enable/Disable Wireless Radio, Wireless Schedule, WMM, Wireless
Statistics | WAN Failover | Yes | Wireless Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK encryptions | Network Type | 4G: FDD-LTE: B1/B3/B5/B7/B8/B20/B28 (2100/1800/850/2600/900/800/700 MHz)
TDD-LTE: B38/B40/B41 (2600/2300/2500 MHz)
3G: DC-HSPA+/HSPA/UMTS: B1/B5/B8(2100/850/900 MHz) | SOFTWARE FEATURES | Quality of Service | WMM, QoS | Operating Modes | 3G/4G Router, Wireless Router | WAN Type | Dynamic IP/Static IP/PPPoE/PPTP(Dual Access)/L2TP(Dual Access) | Management | Access Control, Local Management, Remote Management | DHCP | Server, Client, DHCP Client List, Address Reservation | Port Forwarding | Virtual Server, Port Triggering, UPnP, DMZ | Dynamic DNS | TP-Link DDNS, DynDns, NO-IP | VPN Pass-Through | PPTP, L2TP, IPSec | Access Control | Parental Controls, Local Management Control, Host List, Access Control | Firewall Security | DoS, SPI Firewall, IP and MAC Address Binding | Protocols | Supports IPv4 and IPv6 | Guest Network | 2.4 GHz Guest Network | VPN Server | PPTP VPN, OpenVPN | OTHERS | Certification | CE, RoHS | Package Contents | 300 Mbps Wireless N 4G LTE Telephony Router, TL-MR6500v
RJ45 Ethernet Cable
Power Adapter
Quick Installation Guide | System Requirements | Microsoft Windows 98SE, NT, 2000, XP, Vistaâ„¢ or Windows 7, 8, 8.1, 10
MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0 browsers or higher, or other Java-enabled browsers Nano SIM Card | Environment | Operating Temperature: 0℃~40℃ (32℉ ~104℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing | TELEPHONY | VoIP Standards | SIP(RFC3261)/RTP(RFC1889/3550), G.711A/u, G.729AB, G.726 | Integrated Answering Machine | Stores 100 minutes long voice messages internally on the modem router | Advanced Telephone Functions | Call Blocking, Anonymous Call Blocks, Speed Dial, Emergency Number |
|
