TP-Link EAP225 Omada AC1350 Wireless Dual Band Gigabit Ceiling Mount Access Point

TP-Link EAP225 Omada AC1350 Wireless Dual Band Gigabit Ceiling Mount Access Point
  • 36626_thumb_P_1561529955932
  • 36626_thumb_P_1561529972695
  • 36626_thumb_P_1561529972677
  • 36626_thumb_P_1561529973766
  • 36626_thumb_P_1561529974535
$139.0
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

By clicking Let me know, you agree to our Terms & Conditions and to receive email updates and exclusive promotions, which you may unsubscribe from any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    TP-Link EAP225 Omada AC1350 Wireless Dual Band Gigabit Ceiling Mount Access Point
  • Model Number:
    EAP225
  • Brand:
  • Manufacturer Warranty:
    5 Year

Description

TP-Link EAP225 Omada AC1350 Wireless Dual Band Gigabit Ceiling Mount Access Point





SPECIFICATIONS:

HARDWARE FEATURES

Interface

Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *)

Button

Reset

Power supply

802.3af/A PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Power consumption

EU: 10.5 W
US: 12.6W

Dimensions

8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1   mm)

Antenna type

3 Internal Omni *
2.4GHz: 4dBi
5GHz: 5dBi

Mounting

Ceiling /Wall Mounting (Kits included)

Physical security lock

Yes

Hardware watch dog

Yes

Interface

Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *)

Button

Reset

Power supply

802.3af/A PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)

Power consumption

EU: 10.5 W
US: 12.6W

Dimensions

8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm)

Antenna type

3 Internal Omni *
2.4GHz: 4dBi
5GHz: 5dBi

Mounting

Ceiling /Wall Mounting (Kits included)

Physical security   lock

Yes

Hardware watch dog

Yes

WIRELESS FEATURES

Wireless standards

IEEE 802.11ac/n/g/b/a

Frequency

2.4GHz and 5GHz

Signal rate

5GHz:Up to 867Mbps
2.4GHz:Up to 450Mbps *

Wireless functions

Multiple SSIDs (Up to 16   SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Band Steering
Load Balance
MU-MIMO *
Airtime Fairness *
Beamforming *
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client

Wireless security

Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support

Transmission power

CE:
≤20dBm(2.4GHz,EIRP)
≤23dBm(5GHz,EIRP)
FCC:
≤24dBm(2.4GHz)
≤22dBm(5GHz)

MANAGEMENT

Omada cloud access

Yes

Omada app

Yes

Omada cloud   controller

Yes

Omada controller   software

Yes

EAP controller   software

Yes

Email alerts

Yes

LED on/off control

Yes

Management mac access control

Yes

SNMP

v1,v2c

System logging local/remote syslog

Local/Remote Syslog

TELNET

Yes

SSH

Yes

Web-based management

HTTP/HTTPS

L3 management

Yes

Multi-site management

Yes

Management VLAN

Yes

OTHERS

Certification

CE, FCC, RoHS

Package contents

AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide

System requirements

Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10

Environment

Operating Temperature: 0℃~60℃(32℉~144℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Certification

CE, FCC, RoHS

Package contents

AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide

System requirements

Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10

Environment

Operating Temperature: 0 ~60  (32 ~144 )
Storage Temperature: -40
~70  (-40 ~158 )
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
