Standards and Protocols

Wi-Fi 6

IEEE 802.11ax/ac/n/a 5 GHz

IEEE 802.11n/b/g 2.4 GHz

WiFi Speeds

AX1500

5 GHz: 1201 Mbps (802.11ax)

2.4 GHz: 300 Mbps (802.11n)

WiFi Range

1-2 Bedroom Houses (1-pack)

TP-Link Mesh Technology

Optional Ethernet backhaul work together to link Deco units to   provide seamless coverage

2× Antennas (Internal)

Multiple antennas form a signal-boosting array to cover more   directions and large areas

Beamforming

Concentrates wireless signal strength towards clients to expand WiFi   range

WiFi Capacity

High

Dual-Band

Distribute devices to different bands for optimal performance

2×2 MU-MIMO

Simultaneously communicates with multiple MU-MIMO clients

OFDMA

Simultaneously communicates with multiple WiFi 6 clients

4 Streams

More than enough bandwidth for connected devices

Working Modes

Router Mode

Access Point Mode

SECURITY

Network Security

SPI Firewall

Access Control

Guest Network

1× 5 GHz Guest Network

1× 2.4 GHz Guest Network

WiFi Encryption

WPA-Personal

WPA2-Personal

WPA3-Personal

HARDWARE

Ethernet Ports

2× Gigabit Ports

*Per Deco Unit

Supports WAN/LAN auto-sensing

Buttons Reset

Button

SOFTWARE

Protocols

IPv4

IPv6

Parental Controls

Parental Controls

Custom Profiles

Professional Content Filter Library

Family Time

Bedtime

Off Time

Time Rewards

Family Online Time Ranking

Pause the Internet

Weekly and Monthly Reports

WAN Types

Dynamic IP

Static IP

PPPoE

PPTP

L2TP

Quality of Service

QoS by Device

Cloud Service

OTA Firmware Upgrade

TP-Link ID

DDNS

NAT Forwarding

Port Forwarding

UPnP

IPTV

IGMP Proxy

IGMP Snooping

Bridge

Tag VLAN

DHCP

Address Reservation

DHCP Client List

Server

DDNS

TP-Link

Management Features

Deco App

TEST DATA

WiFi Transmission Power

CE:

<20 dBm (2.4 GHz)

<30 dBm (5 GHz)

FCC:

<30 dBm (2.4 GHz)

<30 dBm (5 GHz)

PHYSICAL

Dimensions (W×D×H)

4.33 × 4.33 × 4.49 in

(110 × 110 × 114 mm)

Package Content

Deco X1500 (1-pack)

1 Deco X1500 Unit

1 RJ45 Ethernet Cable

1 Power Adapter

Quick Installation Guide

OTHERS

System Requirements

Android 5.0 or later

iOS 9.0 or later

*Note: The minimum system requirements will be updated alongside updates to the app, subject to official website information.

Certifications

CE, FCC, RoHS, JPA, JRF, VCCI, NCC, BSMI

Environment

Operating Temperature: 0℃~40℃ (32℉ ~104℉)

Storage Temperature: -40℃~60℃ (-40℉ ~140℉)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing
