Ports

2 WAN/LAN Gigabit Ethernet Ports, 1 Power Port

Buttons

1 Reset button on the underside

Antenna Type

2 internal dual-band antennas per Deco unit

Dimensions

7.5 × 3.6 × 3.6 in. (190.5 × 90.7 × 90.7   mm)

Power Adapter Input

100-240V~ 50/60Hz 0.3A

Power Adapter Output

12V ⎓ 1A

WIRELESS

Wireless Standards

IEEE 802.11 ac/n/a 5 GHz, IEEE 802.11 b/g/n 2.4 GHz

Frequency

2.4 GHz and 5 GHz

Signal Rate

867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz

Transmit Power

FCC: <30 dBm, CE: <20 dBm (2.4 GHz), <23 dBm (5 GHz)

Wireless Security

WPA-PSK/WPA2-PSK

SOFTWARE

Working Mode

Router, Access Point

WAN Type

Dynamic IP/Static IP/PPPoE/L2TP/PPTP

DHCP

Server, Client

Quality of Service

WMM

Firewall Security

SPI Firewall

Protocols

Supports IPv4 and IPv6

Guest Network

2.4 GHz guest network x 1, 5 GHz guest network x 1

Features

Parental Controls, QoS (Quality of Service), Reporting, Assisted Setup, Address Reservation, Port Forwarding, TP-Link DDNS, VLAN,   IPv6, LED Control

Management

Local Management, Remote Management

OTHERS

Certification

CE, FCC, IC, NCC, BSMI, IDA, RCM, JPA, JRF, VCCI, KC, RoHS

Environment

Operating Temperature: 0°C~40°C (32°F~104°F)

Storage Temperature: -40°C~70°C (-40°F~158°F)

Operating Humidity: 10%~90% non-condensing

Storage Humidity: 5%~90% non-condensing

Package Contents

2 Deco units

2 Power Adapters

1 RJ45 Ethernet Cable
