Thermal Grizzly PhaseSheet PTM 50x40mm (TG-PS-50-40)

Thermal Grizzly PhaseSheet PTM 50x40mm (TG-PS-50-40)
  • Thermal-Paste-Thermal-Grizzly-PhaseSheet-PTM-50x40mm-TG-PS-50-40-4
  • Thermal-Paste-Thermal-Grizzly-PhaseSheet-PTM-50x40mm-TG-PS-50-40-1
  • Thermal-Paste-Thermal-Grizzly-PhaseSheet-PTM-50x40mm-TG-PS-50-40-2
$19.0
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Delivery:

- +
Want to be notified when this item is back in stock?

Please enter a valid email address

By clicking 'Notify Me', you agree to our Terms & Conditions and consent to receive email updates. You can unsubscribe at any time.

WishAdd to Wishlist

Buy Now, Pay Later:
Buy now with PayPal
   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Thermal Grizzly PhaseSheet PTM 50x40mm (TG-PS-50-40)
  • Model Number:
    TG-PS-50-40
  • Brand:
  • Warranty Period:
    1 Year

Description

Thermal Grizzly PhaseSheet PTM 50x40mm
The phase-change material on which the PhaseSheet PTM is based is solid at room temperature. The material only begins to liquefy at temperatures above 45 degrees Celsius. A high contact pressure of around 300-400N is required for optimum distribution of the liquid PhaseSheet PTM and thus the lowest possible layer thickness. PhaseSheet PTM has a very low viscosity in its liquid state and contracts again when it changes to a solid material, thus minimizing the pump-out effect.

The pump-out effect is particularly pronounced when combining a copper cooler on a graphics chip because silicon and copper have different linear expansion when heated. The temperatures under load cause the heatspreader and the base plate to deform (concave or convex) and return to their original shape (straight) when they cool down. As a result, the thermal paste is slowly pressed out between the heatspreader and the base plate of the CPU cooler, for example.

  • Outstanding thermal conductivity

  • Consistently high performance

  • Very long service life

  • Versatile in application

  • Not electrically conductive

  • Easy to use


PhaseSheet PTM is more durable than traditional thermal pastes, but not as durable as KryoSheet, for example, which is virtually maintenance-free. PhaseSheet PTM develops and stabilizes its maximum thermal conductivity after around ten thermal cycles above 60 degrees Celsius.



SPECIFICATIONS:

Color

Grey

Operating temperature

-75°C to +150°C
