Processor Architecture

x86 64-bit

Processor Frequency

Quad Core 2.0 GHz (Max burst up to 2.9   GHz)

Hardware Transcoding Engine

H.264, H.265, MPEG-4, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60

Hardware Encryption Engine

√

System Memory

4 GB DDR4 non-ECC SODIMM

Pre-installed Memory Module

4 GB DDR4 non-ECC SODIMM (1x 4GB)

Total Memory Slot Number

1 (DDR4 SODIMM)

Maximum Supported Memory

16GB DDR4 non-ECC SODIMM

Disk Slot Number

2

Compatible Drive types

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

Maximum Internal Raw Storage Capacity

60TB (30TB x2) (Capacity may vary by RAID types)

RAID Migration

√

Drive Hot Swap

√

Internal Drive

Btrfs, EXT4

External Drive

EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS

RJ-45 2.5GbE Network Port

1

USB3.2 Host Port

2  x 10   Gbps + 1  x 5 Gbps

HDMI

1 x HDMI

Size (H*W*D)

222 x 119 x 154 mm

Packaging Size (H*W*D)

258 x 220 x 170 mm

Weight

Net Weight: 1.5Kg , Gross Weight: 2.3 Kg

System Fan

80 x 80 x 25mm  1PCS

Fan Mode

Smart, High speed, Middle speed, Low speed

Noise Level

19.0 dB(A) （Using 2 SATA HDDs/SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m）

Power Supply

48 W

AC Input Voltage

100V - 240V AC

Current Frequency

50/60 Hz, Single frequency
