Processor Architecture

x86 64-bit

Processor Frequency

Quad Core 2.0 GHz (Max burst up to 2.9 GHz)

CPU Single-Core Score

/

Hardware Transcoding Engine

H.264, H.265, MPEG-4, VC-1; maximum resolution: 4K (4096 x 2160); maximum frame rate per second (FPS): 60

Hardware Encryption Engine

√

System Memory

4 GB DDR4 non-ECC SODIMM

Pre-installed Memory Module

4 GB DDR4 non-ECC SODIMM (1x 4GB)

Total Memory Slot Number

1 (DDR4 SODIMM)

Maximum Supported Memory

16GB DDR4 non-ECC SODIMM

Disk Slot Number

4

Compatible Drive types

3.5" SATA HDD

2.5" SATA HDD

2.5" SATA SSD

Maximum Internal Raw Storage Capacity

120 TB (30TB x4) (Capacity may vary by RAID types)

RAID Migration

√

Drive Hot Swap

√

Internal Drive

Btrfs, EXT4

External Drive

EXT3, EXT4, NTFS, FAT32, HFS+, BTRFS

RJ-45 2.5GbE Network Port

1

USB3.2 Host Port

2  x   10 Gbps + 1  x 5 Gbps

HDMI

1 x HDMI

Size (H*W*D)

222 x 179 x 154 mm

Packaging Size (H*W*D)

300 x 275 x 186    mm

Weight

Net Weight: 2.1 Kg , Gross Weight: 3.2 Kg

System Fan

120 x 120 x 25mm    1PCS

Fan Mode

Smart, High speed, Middle speed, Low speed

Noise Level

21.0 dB(A) （Using 2 SATA HDDs/SSDs in standby mode; Test environment noise: 17.3dB(A); Test distance: 1m）

Power Supply

90 W

Redundancy Power Supply

/

AC Input Voltage

100V - 240V AC

Current Frequency

50/60 Hz, Single frequency
