NUMBER OF HARD DISKS

5

COMPATIBLE HARD DISKS

3.5-inch SATA hard disk drive

2.5-inch   SATA hard disk drive

2.5-inch   SSD

MAX. STORAGE CAPACITY

60TB (12TB HDD * 5, the net   capacity may vary according to RAID type)

DATA TRANSMISSION INTERFACE

Thunderbolt 3 *2

DATA CABLE

20Gbps Thunderbolt Cable,   length: 1m

DP INTERFACE

DP1.2

POWER INTERFACE

DC IN 12V

HDD FORMAT

FAT 32, FAT 16, NTFS, and EXT4

READ-WRITE SPEED (MAX.)

Read: 1035MB/sec

Write:   850MB/sec (Use SSD under RAID 0 mode)

SUPPORTED OPERATING SYSTEMS

64-bit Windows 8/10; Mac OS   10.12 (or later version)

DEVICE SIZE

227 x 225 x 136 mm

WEIGHT

Net weight: 2.46 kg

Gross   weight: 3.94 kg

SYSTEM FAN

80 mm x 80 mm x 2 Pcs

FAN TYPE

Temperature controlled

NOISE LEVEL

19.5 dB (A)

SHELL MATERIAL

Aluminum alloy

INPUT VOLTAGE

100V ~ 240V AC

CURRENT FREQUENCY

50/60 HZ, single-frequency

POWER

Operating mode:   76.8W

Sleep   mode: 2.6W (five 2TB hard disks)

RAIDS SUPPORTED

RAID 0, RAID 1, RAID 5, RAID   10, JBOD, and Single

RAID ONLINE EXPANSION

RAID 1, RAID 5,  and RAID   10

RAID MIGRATION

Single to RAID 1

Single   to RAID 5

RAID 1   to RAID 5

Online   RAID Level Migration (ORLM) and RAID Online Capacity Expansion (OCE) are only   supported in Windows, but not in Mac as the Mac OS itself does not support   these functions.

RAID AUTO-REBUILDING

√

HDD HOT PLUG

√

HDD SLEEP

√

HDD S.M.A.R.T. INSPECTION

√

SECTOR INSPECTION AND PARITY CHECK

√

READ-WRITE CACHE

√

DAISY CHAIN CASCADING

√

HDD NCQ TECHNOLOGY

√

EMAIL ALERT NOTICE

√

EVENT LOG

√

WORKING TEMPERATURE

5 °C ~ 40 °C

STORAGE TEMPERATURE

-20 °C ~ 60 °C

RELATIVE HUMIDITY

5% ~ 95% RH

CERTIFICATIONS

CCC, CE, FCC, and UL

WARRANTY   PERIOD

2 years

ROHS   COMPLIANCE

√

PACKAGING   LIST

Product unit * 1

Quick installation guide * 1

Accessories package * 1   (screws)

Power supply * 1

Power cord * 1

Thunderbolt cable (20Gbps) * 1
