Standard&Protocol

IEEE802.3, IEEE802.3u, IEEE802.3ab

CPU

4-Core 2GHz CPU

RAM

512MB

Interface

2*10/100/1000/2500Mbps WAN/LAN ports

3*10/100/1000Mbps WAN/LAN ports

Antenna

5*external antennas

Button

1*Mesh/WPS button, 1*Reset button

Power

Input: AC 100-240V~50/60Hz, 0.5A

Output: DC12V⎓2A

LED indicator

1* LED

Dimensions

(L*W*H) 290.25mm* 52.4mm*230mm

WIRELESS FEATURES

Wireless Standards

IEEE 802.11be/ax/ac/n/a 5 GHz

IEEE 802.11be/ax/n/b/g 2.4 GHz

Data Rate

5 GHz: 5765 Mbps (802.11be, HE160)

2.4 GHz: 1376 Mbps (802.11be)

Frequency

CE:

2.4G: 2412-2472MHz(CH1-CH13)

5G: 5150-5350MHz(CH36-CH64)

FCC:

2.4G: 2412-2462MHz(CH1-CH11)

5G: 5150-5350MHz(CH36-CH64)

5725-5850MHz(CH149-CH165)

Transmission Power

CE:

＜20 dBm（2.4 GHz）

＜23 dBm（5 GHz）

FCC:

＜30 dBm（2.4 GHz）

＜30 dBm（5 GHz）

Basic Features

SSID broadcasting and hiding

MU-MIMO

Beamforming signal directional transmission technology

OFDMA

Multi-Link Operation（MLO）

4K-QAM

Multi-RUs

Wireless Security

WPA2-PSK

WPA3-SAE/WPA2-PSK

Wireless Security: Enable/Disable

WPS（WiFi Protected Set-up) fast encryption

SOFTWARE FUNCTION

Internet Connection Type

PPPoE, Dynamic IP, Static IP

PPPoE(Russia), PPTP(Russia), L2TP(Russia)

Unify, Maxis, Maxis-special, Celcom, Digi

Network Protocol

IPv4&IPv6

Operating Mode

Router Mode

AP Mode

Universal Repeater Mode（Client+AP,WISP）

DHCP

DHCP Server

DHCP Client List

DHCP Static IP Address Reservation and Allocation

Parental Control

Client Filter

URL Filter

Time Limit

Virtual Server

Port Forwarding

DMZ Host

UPnP

Firewall

ICMP Flood Attack Defense

TCP Flood Attack Defense

UDP Flood Attack Defense

Block Ping From WAN

DDNS

DynDNS, no-ip, oray, 88ip

VPN

IPSec Transparent Transmission

PPTP Transparent Transmission

L2TP Transparent Transmission

PPTP VPN Server

PPTP VPN Client

L2TP VPN Client

OpenVPN Client

WireGuard Client

Special Features

WAN/LAN Port Auto-Negotiation

EasyMesh

Smart Diagnosis

Wi-Fi timer switch

Wireless power adjustment

NFC

IPTV

IPv6

IoT Network

Power Control

Smart LED on/off

Other Function

Support App and Web Management

Bandwidth Control

Guest Network

MAC Address Clone

Supports black list and white list

Unify 2.4GHz & 5GHz

Static Routing

Remote Web Management

Backup & Restore configurations

Firmware upgrade online

OTHER FEATURES

Certification

CE, FCC,RoHS

Temperature

Operating Temperature : 0℃~40℃

Storage Temperature : -40C ~70℃

Humidity

Operating Humidity: 10%~90% RH non-condensing

Storage Humidity: 5%~90% RH non-condensing

Package Content

Wi-Fi Router *1

Cat 6 Cable*1

NFC Sticker*1

Power Adapter*1

Quick Installation Guide*1
