CPU Model

Intel Celeron J4125

CPU Quantity

1

CPU Core

4

CPU Architecture

64-bit

CPU Frequency

2.0 (base) / 2.7 (turbo) GHz

Hardware Encryption Engine

✓

MEMORY

System Memory

2 GB DDR4 non-ECC

Total Memory Slots

1

Maximum Memory Capacity

6 GB (2 GB + 4 GB)

Notes

Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.

Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.

STORAGE

Drive Bays

4

M.2 Drive Slots

2 (NVMe)

Drive Type (See all supported drives)

3.5" SATA HDD

2.5" SATA SSD

M.2 2280 NVMe SSD

Hot Swappable Drive*

✓

Notes

The hot swappable drive feature is not supported by M.2 SSD slots.

Compatible drives are mandatory.

EXTERNAL PORTS

RJ-45 1GbE LAN Port

1

RJ-45 2.5GbE LAN Port

1

USB 3.2 Gen 1 Port

2

Notes

MTU value of 1GbE LAN port has a limit of 1500.

APPEARANCE

Size (Height x Width x Depth)

166 mm x 199 mm x 223 mm

Weight

2.18 kg

OTHERS

System Fan

92 mm x 92 mm x 2 pcs

Fan Speed Mode

Full-Speed Mode

Cool Mode

Quiet Mode

Brightness Adjustable Front LED Indicators

✓

Power Recovery

✓

Noise Level*

21.6 dB(A)

Scheduled Power On / Off

✓

Wake on LAN / WAN

✓

Power Supply Unit / Adapter

90 watts

AC Input Power Voltage

100V to 240V AC

Power Frequency

50/60 Hz, Single Phase

Power Consumption*

28.25 watts (Access)

6.10 watts (HDD Hibernation)

British Thermal Unit

96.33 BTU/hr (Access)

20.79 BTU/hr (HDD Hibernation)

Notes

For more information on how power consumption is measured, refer to this article.

Noise testing was conducted with the Synology system fully installed with Synology SATA SSDs and in an idle state. Two G.R.A.S. type 40AE microphones were placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%.

Operating Temperature

0°C to 40°C (32°F to 104°F)

Storage Temperature

-20°C to 60°C (-5°F to 140°F)

Operating Humidity

8% to 80% RH

Storage Humidity

5% to 95% RH

Certification

FCC

CE

BSMI

VCCI

RCM

UKCA

EAC

CCC

KC

BIS

Environment

RoHS Compliant

Packaging Content

Main Unit X 1

Accessory Pack X 1

AC Power Adapter X 1

AC Power Cord X 1

RJ-45 LAN Cable X 2
