Internal Ports

1 - SATA Power (15 pin)

External Ports

2 - USB 3.2 Type-A (9 pin, Gen 2, 10Gbps)

Operating Temperature

5°C to 50°C (41°F to 122°F)

Storage Temperature

-20°C to 60°C (-4°F to 140°F)

Humidity

20%~80% RH

Ports

2

Interface

PCI Express x4

Bus Type

USB 3.2 Gen 2 10Gbps

Card Type

Standard Profile (LP bracket incl.)

Port Style

Integrated on Card

Industry Standards

USB 3.2 Specification

PCI Express Base Specification Rev. 3.0

Intel xHCI Specification Rev. 1.1

UASP (USB Attached SCSI Protocol) Rev. 1.0

Chipset ID

ASMedia - ASM3142

Package Height

1.4 in [3.5 cm]

Package Length

5.7 in [14.5 cm]

Shipping (Package) Weight

4.8 oz [135.0 g]

Package Width

8.5 in [21.5 cm]

Package Quantity

1

Total USB Power Output

4.5W (5V @ 0.9A) nominal, per port - Current draw above 2.0A (10W) will initiate Over-Current Protection

Maximum Data Transfer Rate

10Gbps

Type and Rate

USB 3.2 Gen 2 - 10 Gbit/s

UASP Support

Yes

Color

Black

Product Height

0.7 in [1.9 cm]

Product Length

3.9 in [10.0 cm]

Weight of Product

2.3 oz [65.0 g]

Product Width

4.7 in [12.0 cm]

OS Compatibility

Windows® 7, 8, 8.1, 10, 11

Windows Server® 2012 R2, 2016, 2019, 2022

macOS 10.13 to 10.15, 11.0, 12.0, 13.0, 14.0

Linux® 3.5 and up - LTS Versions only

System and Cable Requirements

PCI Express enabled computer or server with a PCI Express x4 slot or higher (x8, x16)

Included in Package

1 - USB 3.1 Card

1 - Full-Profile Bracket (Pre-Installed)

1 - Low-Profile Bracket

1 - Quick Start Guide
