Max. DC Output

1000W

Load Range

Output

Max.(Amps)

Min.(Amps)

Range (%)

Line   Reg.(%)

Ripple(mVp-p)

+3.3V

25A

0A

±3%

±1%

40mV

+5V

25A

0A

±3%

±1%

40mV

+12V

83.3A

0A

±3%

±1%

100mV

+5VSB

3.0A

0A

±5%

±1%

40mV

-12V

0.3A

0A

±10%

±1%

80mV

Combined +3.3V & +5V

125W

Combined +12V

999.6W

Input Voltage

90 ~ 264 Vrms

Input Frequency Range

47Hz ~ 63Hz

PFC

Active PFC（PF>0.9 at full load）

Efficiency

89% ~ 91% overall efficiency

MTBF

100,000 hours

Operating temperature

0°C ~ 50°C

Protection

Over Current Protection

Over Power Protection

Over Voltage Protection

Short Circuit Protection

Over Temperature Protection

Under Voltage Protection

Connectors

1 x 24 / 20-Pin motherboard connector

2 x 8 / 4-Pin EPS / ATX 12V connector

4 x 8 / 6-Pin PCIe connectors

1 x 12+4-Pin 12VHPWR connector

8 x SATA connector

3 x 4-Pin Peripheral connector + 1 x 4-Pin Floppy adapter connector

Cooling System

Single 120mm dual ball bearing fan

Noise Level

0 ~ 36 dBA

Certification

Cybenetics Platinum

Form factor

SFX-L

Dimension

125mm (W) x 63.5mm (H) x 130mm (D)

4.92” (W) x 2.5” (H) x 5.12” (D)

Weight

1.39 kg

Other

GPU Support list

Compatible with ATX12V v2.4
