GENERAL FEATURE |
|
Application | Client PCs, Game Consoles |
Rated Capacity | 8,000GB (1GB=1 Billion byte by IDEMA) * Actual usable capacity may be less (due to formatting, partitioning, operating system, applications or otherwise) |
Form Factor | M.2 (2280) |
Interface | PCIe® 5.0 x4, NVMe™ 2.0 |
Dimension (WxHxD) | Max 80.15 x Max 25 x Max 11.25mm (with Heatsink) |
Weight | Max 35.0g Weight |
Storage Memory | Samsung V-NAND TLC |
Controller | Samsung in-house Controller |
Cache Memory | Samsung 8GB Low Power DDR4X SDRAM |
SPECIAL FEATURE |
|
TRIM Support | Supported |
S.M.A.R.T Support | Supported |
GC (Garbage Collection) | Auto Garbage Collection Algorithm |
Encryption Support | AES 256-bit Encryption (Class 0)TCG/Opal IEEE1667 (Encrypted drive) |
WWN Support | Not supported |
Device Sleep Mode Support | Yes |
PERFORMANCE |
|
Sequential Read | Up to 14,800 MB/s * Performance may vary based on system hardware & configuration |
Sequential Write | Up to 13,400 MB/s * Performance may vary based on system hardware & configuration |
Random Read | Up to 2,200,000 IOPS * Performance may vary based on system hardware & configuration |
Random Write | Up to 2,600,000 IOPS * Performance may vary based on system hardware & configuration |
ENVIRONMENT |
|
Average Power Consumption (system level) | Average: Read 10.5 W / Write 8.8 W* Actual power consumption may vary depending on system hardware & configuration |
Power consumption (Idle) | Typical 9.3 mW * Actual power consumption may vary depending on system hardware & configuration |
Power Consumption (Device Sleep) | Typical 8.6 mW * Actual power consumption may vary depending on system hardware & configuration |
Allowable Voltage | 3.3 V ± 5 % Allowable voltage |
Reliability (MTBF) | 1.5 Million Hours Reliability (MTBF) |
Operating Temperature | 0 - 70 ℃ Operating Temperature |
Shock | 1,500 G & 0.5 ms (Half sine) |
SOFTWARE |
|
Management SW | Magician Software for SSD management |
