CPU: Intel® Core™ i3-8100 4-core 3.6 GHz processor
Architecture: 64-bit
Graphics: Intel® UHD Graphics 630
Encryption Acceleration: AES-NI
System Memory: 4 GB UDIMM DDR4 (1 x 4 GB)
Maximum Memory: 64 GB ( 4 x 16 GB)
Memory Slot: 4 x Long-DIMM DDR4 (For dual- or quad-DIMM configurations, you must use a pair of identical DDR4 modules.)
Flash Memory: 4 GB (Dual boot OS protection)
Drive Bay: Hot-swappable 8 x 3.5-inch SATA 6 Gbps bays
Drive Compatibility: 3.5-inch bays:
3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives
10 Gigabit Ethernet Port: 2 x 10GbE SFP+ SmartNIC ports
Gigabit Ethernet Port: 4 x RJ45
PCIe Slot: 4
Slot 1: PCIe Gen2 x4 (PCH)
Slot 2: PCIe Gen3 x8 (CPU)
Slot 3: PCIe Gen3 x4 (CPU)
Slot 4: PCIe Gen3 x4 (CPU)
Note: Slot 4 is preinstalled with a 10GbE network adapter
USB Port: 2 x Type-C USB 3.1 Gen2 10Gbps
4 x Type-A USB 3.1 Gen2 10Gbps
HDMI Output: 1 x HDMI 2.0, up to 3840 x 2160, @60Hz
LED Indicators: HDD 1-8, Status, LAN, Storage expansion port status
Buttons: Power, Reset
System Warning: Voice prompts
Form Factor: 2U Rackmount
Dimensions (H x W x D): 88.3 x 482 x 562 mm
WeightNet weight: 11.89 kg
Gross Weight: 15.49 kg
Power Supply Unit: 300W (x2), 100-240V
Power Consumption (W): In operation: 90.2 W (with WD10EFRX drives fully populated)
Fan: System: 2 x 6.0cm fan (12V DC)
Sound Level: Sound pressure (LpAm): 52.1 dB(A)
Operating Temperature & Relative Humidity: 0 ~ 40˚C ( 32˚F ~ 104˚F ), 5 ~ 95% RH non-condensing, wet bulb: 27˚C (80.6˚F)
Security Slot: Kensington Security Slot
