CPU Architecture

64-bit x86

Graphic Processors

ZhaoXin C-960 Graphics

Floating Point Unit

Y

Encryption Engine

 (AES-NI)

Hardware-accelerated Transcoding

Y

System Memory

8 GB SODIMM DDR4 (1 x 8 GB)

Maximum Memory

64GB (2 x 32 GB)

Memory Slot

2 x SO-DIMM DDR4

For dual-DIMM configuration, you must use a pair   of identical DDR4 modules.

Flash Memory

5GB (Dual boot OS protection)

Drive Bay

6 x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility

3.5-inch bays:
  3.5-inch SATA hard disk drives
  2.5-inch SATA hard disk drives
  2.5-inch SATA solid state drives

Hot-swappable

Y

M.2 Slot

2 x M.2 2280 PCIe Gen 3 x1 or SATA 6Gb/s slots

SSD Cache Acceleration Support

Y

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

2

5 Gigabit Ethernet Port (5G/2.5G/1G/100M)

Optional via an adapter

10 Gigabit Ethernet Port

Optional via an adapter

Wake on LAN (WOL)

Only the 2.5GbE port

Jumbo Frame

Y

PCIe Slot

2
  Slot 1: PCIe Gen 3 x4
  Slot 2: PCIe Gen 3 x4

USB 3.2 Gen 1 port

2

USB 3.2 Gen 2 (10Gbps) Port

2 x Type-A

HDMI Output

1, HDMI 2.0 (up to 3840 x 2160 @ 60Hz)

Form Factor

Tower

LED Indicators

HDD 1-6, Status, LAN, USB, M.2 SSD 1-2

Buttons

Power, Reset, USB Copy

Dimensions (HxWxD)

188.2 × 263.9 × 280.8 mm

Weight (Net)

6.2 kg

Weight (Gross)

7.67 kg

Operating temperature

0 - 40 °C (32°F - 104°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit

250W, 100-240V AC, 50/60Hz, 3.5A

Power Consumption: HDD Sleep Mode

41.897 W

Power Consumption: Operating Mode, Typical

60.794 W

Fan

3 x 80mm, 12VDC

Sound Level

20.2 db(A)

System Warning

Buzzer

Kensington Security Slot

Y

Max. Number of Concurrent Connections (CIFS) - with Max. Memory

2000
