CPU Architecture

64-bit x86

Graphic Processors

Intel® UHD Graphics

Floating Point Unit

Yes

Encryption Engine

(AES-NI)

Hardware-accelerated Transcoding

Yes

System Memory

2 GB SODIMM DDR4 (1 x 2 GB)

Maximum Memory

16 GB (2 x 8GB)

Memory Slot

2 x SODIMM DDR4

For dual-DIMM configuration, you must use a pair of identical DDR4 modules.

Flash Memory

4GB (Dual boot OS protection)

Drive Bay

4 x 3.5-inch SATA 6Gb/s

The system is shipped without HDD.
For the HDD compatibility list, please visit https://www.qnap.com/compatibility/

Drive Compatibility

3.5-inch SATA hard disk drives
2.5-inch SATA hard disk drives
2.5-inch SATA solid state drives

Hot-swappable

Yes

M.2 Slot

2 x M.2 2280 PCIe Gen 3 x1

SSD Cache Acceleration Support

Yes

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

1 (2.5G/1G/100M/10M)

Wake on LAN (WOL)

Yes

Jumbo Frame

Yes

PCIe Slot

1
Slot 1: PCIe Gen 3 x2

USB 2.0 port

2

USB 3.2 Gen 2 (10Gbps) Port

2 x Type-A

HDMI Output

1, HDMI 2.0

Form Factor

Tower

LED Indicators

Power/Status, LAN, USB, HDD1-4

Buttons

Power, USB copy, Reset

Dimensions (HxWxD)

168 × 170 × 226 mm

Weight (Net)

2.26 kg

Weight (Gross)

3.6 kg

Operating Temperature

0 - 40 °C (32°F - 104°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit

90W adapter, 100-240V

Power Consumption: HDD Sleep Mode

11.3 W

Power Consumption: Operating Mode, Typical

25.98 W

Tested with drives fully populated.

Fan

1 x 120mm, 12VDC

System Warning

Buzzer

Kensington Security Slot

Yes

Max. Number of Concurrent Connections (CIFS) - with Max. Memory

1500
