CPU Architecture

64-bit ARM

Graphic Processors

Mali-G52

Floating Point Unit

✓

Encryption Engine

✓

Hardware-accelerated Transcoding

✓

Neural Processing Unit (NPU)

✓

System Memory

4 GB on board (non-expandable)

Note: Reserves some RAM for use as shared graphics memory.

Maximum Memory

4 GB on board (non-expandable)

Flash Memory

4 GB (Dual boot OS protection)

Drive Bay

2x 3.5-inch SATA 6Gb/s, 3Gb/s

Drive Compatibility

3.5-inch bays:

3.5-inch SATA hard disk drives

2.5-inch SATA solid state drives

Hot-swappable

✓

Gigabit Ethernet Port (RJ45)

1

2.5 Gigabit Ethernet Port (2.5G/1G/100M)

1 (2.5G/1G/100M)

Wake on LAN (WOL)

✓

Jumbo Frame

✓

USB 2.0 port

2

USB 3.2 Gen 1 port

1

Form Factor

Tower

LED Indicators

System Status, LAN, USB, HDD1~2

Buttons

Power, Reset, USB Copy

Dimensions (HxWxD)

165 × 102 × 220.6 mm

Dimensions do not include foot pad (foot pad may be up to 30mm / 1.18   inches high depending on model)

Weight (Net)

1.45 kg

Weight (Gross)

2.41 kg

Operating Temperature

0 - 40 °C (32°F - 104°F)

Storage Temperature

-20 - 70°C (-4°F - 158°F)

Relative Humidity

5-95% RH non-condensing, wet bulb: 27˚C (80.6˚F)

Power Supply Unit

Minimum 48W adapter (12VDC), 100-240VAC

Power Consumption: Disk Standby Mode

4.973

Power Consumption: Operating Mode, Typical

13.907 W

Tested with drives fully populated.

Fan

1 x 70mm, 12VDC

System Warning

Buzzer

Kensington Security Slot

✓

Max. Number of Concurrent Connections (CIFS)
- with Max. Memory

200

Package Contents

TS-216G

Ethernet cable x 1

Power cord x 1

AC Adapter

Flat head screw (for 3.5" HDD) x 8

Flat head screw (for 2.5" HDD) x 6

Quick installation guide (QIG)

Drive tray keys x 2

Notes

Use only QNAP memory modules to maintain system performance and stability. For NAS devices with more than one memory slot, use QNAP modules with identical specifications and refer to the hardware user manual to install compatible QNAP memory modules.

Warning: Using unsupported modules may degrade performance, cause errors, or prevent the operating system from starting.
