PICTURE/DISPLAY |
|
Panel Size | 34 inch / 86.36 cm |
Aspect ratio | 21:9 |
LCD panel type | VA LCD |
Backlight type | W-LED system |
Pixel pitch | 0.23175 x 0.23175 mm |
Brightness | 450 nits (SDR), 550 nits (DHR) cd/m² |
Display colors | 16.7 M (8 bit) |
Color gamut (typical) | NTSC area: 9.39%,sRGB area: 120.63%* |
Contrast ratio (typical) | 4000:1 |
SmartContrast | 50,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | HDMI: 3440 x 1440 @ 100 Hz; DP1.4 / Thunderbolt 4: 3440 x 1440 @ 120 Hz * |
Effective viewing area | 797.22 (H) x 333.72 (V) - at a 1500R curvature* |
Scanning Frequency | 30 - 190 kHz (H) / 48 - 120 Hz (V) |
sRGB | Yes |
Delta E | < 2 (for sRGB) |
SoftBlue | Yes |
Flicker-free | Yes |
Pixel Density | 110 PPI |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
SmartUniformity | 93 ~ 105% |
EasyRead | Yes |
Adaptive sync | Yes |
HDR | Supported VESA HDR 400 |
EyeSafe | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, Thunderbolt 4 x 1 (upstream, Data, video, PD up to 100 W) |
Sync Input | Separate Sync Sync on Green |
Audio (In/Out) | Audio out / Microphone in combo jack |
RJ45 | Ethernet LAN up to 2.5G*, Wake on LAN |
Signal Output | Thunderbolt 4 x1 (downstream, data, video, PD 15W) |
HDCP | HDCP 1.4 (HDMI / DisplayPort /Thunderbolt); HDCP 2.2 (HDMI / DisplayPort /Thunderbolt) |
HBR3 | HBR 3 (DisplayPort / Thunderbolt) |
USB Hub | USB 3.2, Gen 2 / 10 Gbps, Upstream: Thunderbolt 4 x 1, USB-C1 (Data) ; Downstream : Thunderbolt4 x 1 , USB-A X 4 (with 1 for fast charge B.C 1.2), USB-C2 x 1 (Data, 45W) |
POWER DELIVERY |
|
Max power delivery | USB up to 100 W* (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.8A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 5 W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience | SmartImage Input User Menu Power On/Off Mute Handup Busylight |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) Earphone hook |
Control software | SmartControl |
MultiView | PIP/PBP mode 2x devices |
Built-in webcam | Pop-up 5.0 megapixel camera with microphone and LED indicator |
Webcam with auto framing | Yes |
Webcam tilt function | Yes, -/+30 degree |
Busylight | Yes |
KVM | Yes (Thunderbolt 4/USB-C1) |
Noise cancellation | Yes |
SmartKVM | Yes |
STAND |
|
Height adjustment | 180 mm |
Swivel | -/+180 degree |
Tilt | -5/30 degree |
POWER |
|
ECO mode | 26.6 W (typ.) |
Power supply | Built-in 100-240VAC, 50-60Hz |
On mode | 31.59 W (typ.) (EnergyStar test method) |
Standby mode | 0.4 W (typ.) |
Power LED indicator | Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 980 x 525 x 188 mm |
Product without stand (mm) | 807 x 369 x 112 mm |
Product with stand (max height) | 807 x 575 x 281 mm |
WEIGHT |
|
Product with packaging (kg) | 11.15 kg |
Product with stand (kg) | 10.61 kg |
Product without stand (kg) | 7.85 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40 °C |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20°C to 60 °C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | PowerSensor 2* LightSensor Energy Star EPEAT* TCO Certified RoHS |
Post consumer recycled plastic | 85%+OBP 5% |
Recyclable packaging material | 100 % |
Specific Substances | Mercury free PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark EPA TUV/GS TUV Ergo TCO Certified EAC EAEU RoHS MEPS UKCA EMF FCC ICES-003 Eyesafe® CERTIFIED 2.0 TÜV Rheinland Low Blue Light (Hardware Solution) |
