PICTURE/DISPLAY |
|
Panel Size | 31.5"/80cm |
Aspect ratio | 16:9 |
LCD panel type | VA LCD |
Backlight type | W-LED system |
Pixel pitch | 0.18159 Ć0.18159 mm |
Brightness | 350 cd/mĀ² |
Display colors | 1.07B (10 bits)* |
Color gamut (typical) | sRGB 122%, NTSC 106 %* |
Contrast ratio (typical) | 3500:1 |
SmartContrast | 50,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178Āŗ (H) / 178Āŗ (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | 3840x2160@60Hz |
Effective viewing area | 697.306 (H) x 392.234 (V)mm |
Scanning Frequency | 30 - 140 kHz (H) /23 - 75 Hz (V) |
sRGB | Yes |
Flicker-free | Yes |
Pixel Density | 140 PPI |
LowBlue Mode | Yes |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
EasyRead | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD up to 90 W) |
Sync Input | Separate Sync |
Audio (In/Out) | Audio out |
RJ45 | Ethernet LAN up to 1G* |
HDCP | HDCP 1.4 (HDMI / DisplayPort / USB-C); HDCP 2.2 (HDMI / DisplayPort / USB-C) |
USB Hub | USB3.2, Gen1, 5G; upstream: USB-C x1 ;downstream: USB-A x4 (with x1 fast charge B.C 1.2) |
POWER DELIVERY |
|
Max power delivery | USB-C up to 90 W* (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.5A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 3 W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience | SmartImage Input Brightness Menu Power On/Off |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) |
Control software | SmartControl |
MultiView | PIP/PBP mode 2x devices |
STAND |
|
Height adjustment | 180 mm |
Pivot | -/+90 degree |
Swivel | -/+180 degree |
Tilt | -5/25 degree |
POWER |
|
ECO mode | 20.4 W (typ.) |
Power supply | Built-in 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ.) |
On mode | 34.8 W (typ.) |
Standby mode | 0.3 W (typ.) |
Power LED indicator | Operation - White Standby mode- White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 930 x 563 x 186 mm |
Product without stand (mm) | 714 x 422 x 62 mm |
Product with stand (max height) | 714 x 631 x 280 mm |
WEIGHT |
|
Product with packaging (kg) | 16.23 kg |
Product with stand (kg) | 11.47 kg |
Product without stand (kg) | 7.56 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0Ā°C to 40 Ā°C |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20Ā°C to 60 Ā°C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | RoHS |
Post consumer recycled plastic | 85% |
Recyclable packaging material | 100 % |
Specific Substances | PVC / BFR free housing Mercury free Lead-free |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark TUV/GS TUV Ergo EAC EAEU RoHS MEPS UKCA EMF FCC ICES-003 |
