PICTURE/DISPLAY |
|
Panel Size | 48.8 inch / 124 cm |
Aspect ratio | 32:9 |
LCD panel type | VA LCD |
Backlight type | W-LED system |
Pixel pitch | 0.2328 x 0.2328 mm |
Brightness | 450 (SDR) cd/m², 500 (HDR) cd/m² |
Display colors | 1.07B |
Color gamut (typical) | NTSC 97%, sRGB 119%* |
Contrast ratio (typical) | 3000:1 |
SmartContrast | 80,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | 5120x1440@75Hz (HDMI/DP/USB-C)* |
Effective viewing area | 1191.936(H)x335.232(V)mm, 1800R curvature* |
Scanning Frequency | HDMI: 30 - 140 kHz (H) / 48-75 Hz (V); DP: 30 - 114 kHz (H) / 48-75 Hz (V); USB-C: 30 - 114 kHz (H) / 30-75 Hz (V) |
sRGB | Yes |
Delta E | < 2 |
SoftBlue | Yes |
Flicker-free | Yes |
Pixel Density | 109 PPI |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
SmartUniformity | 93 ~ 105% |
EasyRead | Yes |
Adaptive sync (VRR) | Yes |
HDR | DisplayHDR 400 certified |
EyeSafe | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x 1 (upstream, DP Alt mode, Data, PD) |
Sync Input | Separate Sync Sync on Green |
Audio (In/Out) | Audio out |
RJ45 | Ethernet LAN up to 1G |
HDCP | HDCP 1.4 (HDMI / DisplayPort / USB-C), HDCP 2.2 (HDMI / DisplayPort / USB-C) |
HBR3 | HBR3 |
USB Hub | USB 3.2 Gen 1 / 5 Gbps, USB-B upstream x 1, USB-A downstream x 2 (with 1 for fast charge B.C 1.2), USB-C downstream x 1 (Data, PD 15W) |
POWER DELIVERY |
|
Max power delivery | up to 100W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A, 20V/4.8A)* |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 3 W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS sRGB Windows 11 / 10 / 8.1 / 8 |
User convenience | SmartImage Input User Menu Power On/Off |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock Earphone hook VESA mount (100x100mm) |
Control software | SmartControl |
MultiView | PIP/PBP mode 2x devices |
KVM | Yes (USB-C/USB-B) Stand |
Height adjustment | 150 mm |
Swivel | -/+30 degree |
Tilt | -5/15 degree |
POWER |
|
ECO mode | 34.18 W (typ.) |
Power supply | Built-in 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ.) |
On mode | 52.27 W (typ.) (EnergyStar test method) |
Standby mode | 0.3 W (typ.) |
Power LED indicator | Operation - White Standby mode - White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 1290 x 475 x 300 mm |
Product without stand (mm) | 1193 x 373 x 164 mm |
Product with stand (max height) | 1193 x 583 x 268 mm |
WEIGHT |
|
Product with packaging (kg) | 22.70 kg |
Product with stand (kg) | 15.30 kg |
Product without stand (kg) | 11.67 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40 °C |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20°C to 60 °C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | PowerSensor LightSensor EnergyStar 8.0 EPEAT* RoHS |
Post consumer recycled plastic | 85%+OBP 5% |
Recyclable packaging material | 100 % |
Specific Substances | Mercury free PVC / BFR free housing Compliance and standards |
Regulatory Approvals | CB CE Mark ETL CEC TUV/GS TUV Ergo TCO Certified TCO Certified Edge EAC EAC ROHS MEPS UKCA EMF FCC ICES-003 TÜV Rheinland Low Blue Light (Hardware Solution) eyesafe® CERTIFIED 2.0 |
CABINET |
|
Finish | Texture |
Foot | Silver |
Front bezel | Charcoal |
Rear cover | Charcoal |
