PICTURE/DISPLAY |
|
Panel Size | 48.8inch/124cm |
Aspect ratio | 32:9 |
LCD panel type | VA LCD |
Backlight type | W-LED system |
Pixel pitch | 0.2328x0.2328mm |
Brightness | 450(SDR) cd/mĀ² , 500(HDR) cd/mĀ² |
Display colors | 1.07 B |
Color gamut (typical) | NTSC: 97%*, sRGB: 119% * |
Contrast ratio (typical) | 3000:1 |
SmartContrast | 80,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178Āŗ (H) / 178Āŗ (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | 5120x1440@60Hz (HDMI2.0)*, 5120x1440@100Hz(DP1.4)*, 5120x1440@75Hz (Thunderbolt)* |
Effective viewing area | 1191.936(H)x335.232(V)mm,1800R curvature* |
Scanning Frequency | HDMI: 30 - 140 kHz (H) / 30-75 Hz (V); DP/Thunderbolt: 30 - 200 kHz (H) / 48-120 Hz (V) |
sRGB | Yes |
Delta E | < 2 (sRGB) |
SoftBlue | Yes |
Flicker-free | Yes |
Pixel Density | 109 PPI |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
SmartUniformity | 93 ~ 105% |
EasyRead | Yes |
Adaptive sync | Yes |
HDR | Display HDR 400 certified |
EyeSafe | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, Thunderbolt 4 input x 1 (upstream, Data, Video, PD to 100W) |
Sync Input | Separate Sync Sync on Green |
Audio (In/Out) | Audio out / Microphone in combo jack |
RJ45 | Ethernet LAN up to 2.5G*, Wake on LAN |
Signal Output | Thunderbolt 4 output x 1 (downstream, Data, Video, PD 15W) |
HDCP | HDCP 1.4 (HDMI / DisplayPort / Thunderbolt 4 ), HDCP 2.2 (HDMI / DisplayPort / Thunderbolt 4 ) |
HBR3 | HBR 3 (Thunderbolt 4 ) |
USB Hub | USB 3.2 Gen 2 / 10 G, upstream: 1x Thunderbolt 4, 1x USB-C1 (data); downstream: 1x Thunderbolt 4, USB-A x4 (with x1 fast charge B.C 1.2), USB-C2x1 (data, 45W) |
POWER DELIVERY |
|
Max power delivery | Up to 100 W (5/V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/4.8A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 5 W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience | SmartImage Input User Menu Power On/Off Mute Handup Busylight |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock Earphone hook VESA mount (100x100mm) |
Control software | SmartControl |
MultiView | PIP/PBP mode 2x devices |
Built-in webcam | Pop-up 5.0 megapixel camera with microphone and LED indicator |
Webcam with auto framing | Yes |
Webcam tilt function | Yes, -/+30 degree |
Busylight | Yes |
Noise cancellation | Yes |
SmartKVM | Yes (Thunderbolt 4/USB-C1) Stand |
Height adjustment | 150 mm |
Swivel | -/+30 degree |
Tilt | -5/15 degree |
POWER |
|
ECO mode | 37.5 W (typ.) |
Power supply | Built-in 100-240VAC, 50-60Hz |
Off mode | 0.5 W (typ.) |
On mode | 41.85 W (typ.) (EnergyStar test method) |
Standby mode | 0.5 W (typ.) |
Power LED indicator | Operation - White Standby mode - White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 1290 x 300 x 475 mm |
Product without stand (mm) | 1193 x 373 x 164 mm |
Product with stand (max height) | 1193 x 586 x 268 mm |
WEIGHT |
|
Product with packaging (kg) | 19.54 kg |
Product with stand (kg) | 15.45 kg |
Product without stand (kg) | 11.82 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0Ā°C to 40 Ā°C |
Relative humidity | 20%-80 % |
Temperature range (storage) | -20Ā°C to 60 Ā°C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | Energy Star EPEAT* RoHS TCO Certified Edge LightSensor PowerSensor 2* |
Post consumer recycled plastic | 85%+OBP 5% |
Recyclable packaging material | 100% |
Specific Substances | Mercury free PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark TUV/GS TUV Ergo TCO Certified MEPS EAC UKCA EMF FCC ICES-003 eyesafeĀ® CERTIFIED 2.0 TĆV Rheinland Low Blue Light (Hardware Solution) |
