PICTURE/DISPLAY |
|
Panel Size | 34 inch / 86.36 cm |
Aspect ratio | 21:9 |
LCD panel type | VA LCD |
Backlight type | W-LED system |
Pixel pitch | 0.23175 x 0.23175 mm |
Optimum resolution | 3440x1440@60Hz |
Brightness | 300 cd/m² |
Display colors | 1.07B (10 bits) |
Color gamut (typical) | NTSC area: 104%, sRGB area: 120%* |
Contrast ratio (typical) | 3500:1 |
SmartContrast | 50,000,000:1 |
Response time (typical) | 4 ms (Gray to Gray)* |
Viewing angle | 178º (H) / 178º (V) @ C/R > 10 |
Picture enhancement | SmartImage |
Maximum resolution | 3440x1440@100Hz(HDMI), 3440x1440@120Hz (DP/USBC) |
Effective viewing area | 797.22 (H) x 333.72 (V) - at a 1500R curvature* |
Scanning Frequency | HDMI: 30K-160KHz (H) /48 - 100 Hz (V), DP/USB-C : 30-190KHZ (H )/ 48 - 120 Hz (V) |
sRGB | Yes |
SoftBlue | Yes |
Flicker-free | Yes |
Pixel Density | 110 PPI |
Display Screen Coating | Anti-Glare, 3H, Haze 25% |
EasyRead | Yes |
Adaptive sync (VRR) | Yes |
HDR | HDR10 supported |
EyeSafe | Yes |
DICOM (D-mode) | Yes |
CONNECTIVITY |
|
Signal Input | HDMI 2.0 x 2, DisplayPort 1.4 x 1, USB-C x1 (upstream, DP Alt mode, data, PD) |
Sync Input | Separate Sync Sync on Green |
Audio (In/Out) | Audio out x 1 |
RJ45 | Ethernet LAN (USB 2.0: 10M/100M; USB 3.0: 1000M), PXE/MAPT/WOL* |
HDCP | HDCP 1.4 (HDMI / DisplayPort / USB-C); HDCP 2.2 (HDMI / DisplayPort / USB-C) |
HBR3 | Yes |
USB Hub | USB3.2, Gen1, 5G, upstream: USB-C1(Full)/USB-C2; downstream: USB-A x4 (with x1 fast charge B.C 1.2) |
POWER DELIVERY |
|
Max power delivery | up to 90W (5V/3A, 7V/3A, 9V/3A, 10V/3A, 12V/3A, 15V/3A, 20V/3.25A, 20V/4.5A) |
Version | USB PD version 3.0 |
CONVENIENCE |
|
Built-in Speakers | 5 W x 2 |
Plug & Play Compatibility | DDC/CI Mac OS sRGB Windows 11 / 10 |
User convenience | SmartImage Input Brightness Menu Power On/Off |
OSD Languages | Brazil Portuguese Czech Dutch English French Finnish German Greek Hungarian Italian Japanese Korean Portuguese Polish Russian Simplified Chinese Spanish Swedish Traditional Chinese Turkish Ukrainian |
Other convenience | Kensington lock VESA mount (100x100mm) |
Control software | SmartControl MultiView 2x devices PIP/PBP mode |
Built-in webcam | 5.0 megapixel camera with microphone and LED indictor (for Windows Hello) |
Webcam tilt function | Yes, -/+30 degree |
SmartKVM | Yes, (USB-C1/USB-C2)* |
STAND |
|
Height adjustment | 180 mm |
Swivel | -/+180 degree |
Tilt | -5/30 degree |
POWER |
|
ECO mode | 21.3 W (typ.) |
Power supply | Built-in 100-240VAC, 50-60Hz |
Off mode | 0.3 W (typ.) |
On mode | 28.26W (typ.) (EnergyStar 8.0 test method) |
Standby mode | 0.3 W (typ.) |
Power LED indicator | Operation - White Standby mode - White (blinking) |
DIMENSIONS |
|
Packaging in mm (WxHxD) | 930 x 525 x 188 mm |
Product without stand (mm) | 807 x 369 x 107 mm |
Product with stand(max height) | 807 x 602 x 287 mm |
WEIGHT |
|
Product with packaging (kg) | 15.35 kg |
Product with stand (kg) | 10.401 kg |
Product without stand (kg) | 7.82 kg |
OPERATING CONDITIONS |
|
Altitude | Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m) |
Temperature range (operation) | 0°C to 40°C |
Relative humidity | 20%-80% |
Temperature range (storage) | -20°C to 60°C |
MTBF (demonstrated) | 70,000 hrs (excluded backlight) |
SUSTAINABILITY |
|
Environmental and energy | EPEAT* Energy Star RoHS |
Post consumer recycled plastic | 85% |
Recyclable packaging material | 100% |
Specific Substances | Mercury free PVC / BFR free housing |
COMPLIANCE AND STANDARDS |
|
Regulatory Approvals | CB CE Mark ETL CEC TCO Certified TCO Certified Edge EAC EAC ROHS MEPS UKCA EMF FCC ICES-003 TUV/GS TUV Ergo eyesafe® CERTIFIED 2.0 TÜV Rheinland Low Blue Light (Hardware Solution) |
CABINET |
|
Finish | Texture |
Foot | Black |
Front bezel | Black |
Rear cover | Black |
