LCD panel type

VA LCD

Backlight type

W-LED system

Panel Size

23.8 inch / 60.5 cm

Display Screen Coating

Anti-Glare, 3H, Haze 25%

Effective viewing area

527 (H) x 296.5 (V)

Aspect ratio

16:9

Maximum resolution

1920 x 1080 @ 75 Hz*

Pixel Density

93 PPI

Response time (typical)

4 ms (GtG)*

Brightness

250  cd/m²

Contrast ratio (typical)

3000:1

SmartContrast

Mega Infinity DCR

Pixel pitch

0.2745 x 0.2745 mm

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Flicker-free

Yes

Display colours

16.7 M

Scanning Frequency

30 - 85 kHz (H) / 48 - 75 Hz (V)

LowBlue Mode

Yes

EasyRead

Yes

sRGB

Yes

Adaptive sync

Yes

CONNECTIVITY

Signal Input

VGA (Analog )

HDMI (digital, HDCP)

Sync Input

Separate Sync

Sync on Green

Audio (In/Out)

Audio out

PC audio-in

CONVENIENCE

Built-in Speakers

2 W x 2

User convenience

Power On/Off

Menu/OK

Volume

Input/Down

SmartImage/Back

OSD Languages

Brazil Portuguese, Czech, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Polish, Portuguese, Russian, Spanish, Simplified Chinese, Swedish, Turkish, Traditional Chinese, Ukrainian

Other convenience

Kensington lock

VESA mount (100x100mm)

Plug & Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 10 / 8.1 / 8 / 7

STAND

Tilt

-5/20  degree

POWER

On mode

20.4 W (typ.)

Standby mode

0.5 W (typ.)

Off mode

0.3 W (typ.)

Power LED indicator

Operation - White

Standby mode- White (blinking)

Power supply

Built-in

100-240VAC, 50-60Hz

DIMENSIONS

Product with stand(max height)

540 x 416 x 220  mm

Product without stand (mm)

540 x 322 x 51  mm

Packaging in mm (WxHxD)

608 x 415 x 121  mm

WEIGHT

Product with stand (kg)

2.97  kg

Product without stand (kg)

2.58  kg

Product with packaging (kg)

4.19  kg

OPERATING CONDITIONS

Temperature range (operation)

0°C to 40°C  °C

Temperature range (storage)

-20°C to 60°C  °C

Relative humidity

20%-80  %

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

MTBF

50,000 (Excluded backlight)  hour(s)

SUSTAINABILITY

Environmental and energy

RoHS

Recyclable packaging material

100  %

Specific Substances

Mercury free

PVC / BFR free housing

COMPLIANCE AND STANDARDS

Regulatory Approvals

UKRAINIAN

CB

TUV Ergo

TUV/GS

CU-EAC

EAEU RoHS

CE Mark

MEPS

RCM

CABINET

Colour

Black

Finish

Textured
