Panel Size

15.6 inch / 39.6 cm

Aspect ratio

16:9

LCD panel type

IPS technology

Backlight type

W-LED system

Pixel pitch

0.17925 x 0.17925 mm

Brightness

250 cd/m²

Display colors

16.7M (6 bits + FRC)

Color gamut (typical)

NTSC 46.96%, sRGB 65.51%,DCI-P3 42.8%*

Contrast ratio (typical)

1200:1

SmartContrast

50,000,000:1

Response time (typical)

4   ms (Gray to Gray)*

Viewing angle

178º (H) / 178º (V)

@ C/R > 10

Picture enhancement

SmartImage

Maximum resolution

1920 x 1080@60Hz

Effective viewing area

344.16 (H) x 193.59mm (V)

Scanning Frequency

30 - 85 kHz (H)/48 - 60 Hz (V)

sRGB

Yes

Flicker-free

Yes

Pixel Density

141.2 PPI

LowBlue Mode

Yes

Display Screen Coating

Anti-Glare, 3H, Haze 25%

EasyRead

Yes

HDR

HDR 10 supported

CONNECTIVITY

Signal Input

micro HDMI 1.4 x 1, USB-C x 2 (DisplayPort Alt mode and Power Delivery 15W)*

Audio (In/Out)

Audio out

HDCP

HDCP 1.4 (micro HDMI / USB-C)

POWER DELIVERY

Max power delivery

Up to 15W (5V/3A)

Version

USB PD version 3.0

USB-C (input)

Reversible plug connector

CONVENIENCE

Plug & Play Compatibility

DDC/CI

Mac OS X

sRGB

Windows 11 / 10

User convenience

Power On/Off

Menu/OK

SmartImage

Input/Down

OSD Languages

Brazil Portuguese

Czech

Dutch

English

French

Finnish

German

Greek

Hungarian

Italian

Japanese

Korean

Portuguese

Polish

Russian

Simplified Chinese

Spanish

Swedish

Traditional Chinese

Turkish

Ukrainian

Other convenience

VESA mount (75x75mm)

STAND

Tilt

0 ~ 90  degree

POWER

Power supply

External

100-240VAC, 50-60Hz

Off mode

0.3   W (typ.)

On mode

9 W (typ.)

Standby mode

0.3   W (typ.)

Power LED indicator

Operation - White

Standby mode- White (blinking)

DIMENSIONS

Packaging in mm (WxHxD)

404 x 281 x 87  mm

Product with stand (max height)

359   x 232 x 120  mm

WEIGHT

Product with packaging (kg)

1.92  kg

Product with stand (kg)

1.03  kg

OPERATING CONDITIONS

Altitude

Operation: +12,000ft (3,658m), Non-operation: +40,000ft (12,192m)

Temperature range (operation)

0°C   to 40  °C

Relative humidity

20%-80  %

Temperature range (storage)

-20°C   to 60  °C

MTBF (demonstrated)

50,000 hrs (excluded backlight)

SUSTAINABILITY

Environmental and energy

China RoHS

Recyclable packaging material

100  %

Specific Substances

PVC / BFR free housing

COMPLIANCE AND STANDARDS

Regulatory Approvals

CCC

CE Mark

CABINET

Finish

Texture

Foot

Black/Black

Front bezel

Black/Black

Rear cover

Black/Black
