CPU

Supports 12th/13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors

LGA 1700

Memory

2x DDR4, Maximum Memory Capacity 64GB

Memory Support DDR4 4266(O.C.) /   4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3800(O.C.) / 3733(O.C.) / 3666(O.C.) / 3600(O.C.) / 3200 / 3000 / 2933 / 2666 / 2400 / 2133 MHz

Supports Intel® XMP 2.0 OC

Supports Dual-Controller Dual-Channel mode

Onboard Graphics

1x VGA

*Support VGA, maximum resolution of 2048x1536 50Hz, 2048x1280 60Hz, 1920x1200 60Hz

1x HDMI™port

*HDMI™ port supports up to 4K@30Hz

*Graphics specifications may vary between CPU types. Please refer to www.intel.com for any updates.

Expansion Slot

1x PCIe 4.0 x16 slot

1x PCIe 3.0 x1 slot

Storage

M.2 slot (Key M), type 2242/2280 (supports PCIe 4.0 x4 mode)

3 x SATA 6Gb/s ports

RAID

Supports RAID 0, RAID 1, RAID 5 and RAID 10 for SATA storage devices

USB

*Front USB (Total 4 ports)

2x USB 3.2 Gen1 Type A

2x USB 2.0

*Rear USB (Total 6 ports)

2x USB 3.2 Gen1 Type A

4x USB 2.0

LAN

Realtek® RTL8111H 1G LAN

Audio

Realtek® ALC897 Codec

5.1-Channel High Definition Audio

Internal I/O

1x 24-pin Power Connector(ATX_PWR)

1x 8-pin Power Connector(CPU_PWR)

1x CPU Fan

1x System Fan

1 x M.2 slots (Key-M)

3x SATA 6Gb/s ports

1x 2-Pin CLR_CMOS

1x 4-Pin BUZZER

1x Front Audio

1x COM_A Port

1x 9-Pin DEBUG_CON

1x 2-Pin ME_PROTECT

Operating System

Support for Windows® 11 64-bit, Windows® 10 64-bit

Form Factor

M-ATX

225mm x 179mm
