Screen Size (class)

75"

Diagonal

74.5" 189.3cm

Panel Type

ADS

Haze

25% (Anti-Glare)

Aspect Ratio

16:9

Native Resolution

3840 × 2160

Refresh Rate

60Hz

Brightness (Typ.)

500 nits

Backlight Type

DLED

Contrast Ratio

1,200:1 (Typ)

1,000,000:1 (Dynamic)

Viewing Angle (H × V)

178°

Response Time

8ms

Life Time (Min.)

50,000 hours

Operation Hours (Hours / Day)

24 / 7

Orientation

Portrait / Landscape

INTERNAL PLAYER

Processor

A55 × 4

Graphic

Mali-G52 × 2

Memory

4G

Storage

32G

Operating System

Android 11.0

UI Resolution

4K

CONNECTIVITY

Input

HDMI IN × 3

USB 2.0 × 1

USB 3.0 × 1

USB Type-C × 1

RS232 × 1

RJ45 IN × 1

Output

HDMI OUT × 1

AUDIO OUT × 1

SPDIF × 1

RJ45 OUT × 1

OPS Slot

Module slot × 1

Wi-Fi Slot

Module slot × 1

Wi-Fi

Wi-Fi 6 supported, 802.11ac/b/g/n/a/ax, 2.4GHz/5GHz

Bluetooth

5.2

ENVIRONMENTAL CONDITIONS

Operation Temperature

0℃ ~  40℃

Operation Humidity

10% ~ 90%RH

Storage Temperature

-20℃ ~  60℃

Storage Humidity

10% ~ 90%RH

MECHANICAL SPECIFICATION

Bezel Width (L × R × T × B)

15.9 / 15.9 / 15.9 / 15.9 mm

Product Dimension (W × H × D)

1685.6 × 963.7 × 81.6 mm

Product Weight (Net)

34.65 kg

VESA Mount (mm)

800 × 600

Handle

Yes

POWER

Power Supply

100-240V~50/60Hz

Power Consumption (Standby mode)

0.5W

Power Consumption (Typical)

170.5W

SOUND

Speaker Power(Max.)

2 × 16W

CERTIFICATION

Safety

IEC 62368-1

EMC

Class B

ErP

Yes

Energy Star

Yes
