PERFORMANCE |
Processor | Intel Core™ Ultra 5 125U, 12C (2P + 8E + 2LPE) / 14T, Max Turbo up to 4.3GHz, 12MB Intel® Smart Cache |
AI PC Category | AI PC |
NPU | Integrated Intel® AI Boost, up to 11 TOPS |
Graphics | Integrated Intel® Graphics |
Chipset | Intel® SoC Platform |
Memory | 32GB Soldered LPDDR5x-6400 |
Memory Slots | Memory soldered to systemboard, no slots, 8-channel |
Max Memory | 32GB soldered memory, not upgradable |
Storage | 512GB SSD M.2 2280 PCIe® 4.0x4 NVMe® Opal 2.0 |
Storage Slot | One M.2 2280 PCIe® 4.0 x4 slot |
Max Storage Support | One drive, up to 2TB M.2 2280 SSD |
Optical | None |
Card Reader | No Card Reader |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3306 codec |
Speakers | Stereo speakers, 2W x2, Dolby Atmos® |
Microphone | 2x, Array |
Camera | FHD 1080p + IR Discrete with Privacy Shutter |
Battery | 57Wh |
Power Adapter | 65W USB-C® (3-pin) |
DESIGN |
Display | 14" WUXGA (1920x1200) IPS 400nits Anti-reflection / Anti-smudge, 100% sRGB, 60Hz, Low Power, Touch |
Touchscreen | OGS, 10-point Multi-touch |
Screen-to-Body Ratio | 87.8% |
Pen | Lenovo® Slim Pen |
Keyboard | Backlit, English |
Touchpad | Trackpad |
Dimensions (WxDxH) | 312.80 x 217.65 x 15.49 mm (12.31 x 8.57 x 0.61 inches) |
Weight | Starting at 1.35 kg (2.97 lbs) |
Case Color | Grey |
Case Material | Aluminium (Top), Aluminium (Bottom) |
SOFTWARE |
Operating System | Windows® 11 Pro, English |
Bundled Software | Intel® Connectivity Performance Suite |
CONNECTIVITY |
WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3, vPro® |
WWAN | WWAN Not Supported |
SIM Card | No physical SIM card inbox |
Ethernet | No Onboard Ethernet |
NFC | No NFC |
Standard Ports | 1x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x USB-A (USB 5Gbps / USB 3.2 Gen 1), Always On 2x USB-C® (Thunderbolt™ 4 / USB4® 40Gbps), with USB PD 3.0 and DisplayPort™ 2.1 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) |
Optional Ports (configured) | None |
Docking | Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® X1 2-in-1 Gen 9 |
SECURITY & PRIVACY |
ThinkShield | ThinkShield is a comprehensive security solution that encompasses hardware, software, and supply chain components. For more detials, visit here |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | Kensington Nano Security Slot™, 2.5 x 6 mm |
Smart Card Reader | No Smart Card Reader |
Fingerprint Reader | Touch Style, Match-on-Chip, in Keyboard Key |
Other Security | Camera privacy shutter Ultrasonic Human Presence Detection (FHD 1080p + IR camera models) IR camera for Windows® Hello (facial recognition) |
MANAGEABILITY |
System Management | Non-vPro® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STAR® 9.0 EPEAT™ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified, generation 10 |
Mil-Spec Test | MIL-STD-810H military test passed |
Other Certifications | Eyesafe® Certified 2.0 Intel Evo™ Platform |
