PERFORMANCE |
Processor | Intel® Core i5-1335U, 10C (2P + 8E) / 12T, P-core 1.3 / 4.6GHz, E-core 0.9 / 3.4GHz, 12MB |
Graphics | Integrated Intel® Iris® Xe Graphics |
Chipset | Intel® SoC Platform |
Memory | 16GB Soldered LPDDR5/x-6400 |
Memory Slots | Memory soldered to systemboard, no slots, 8-channel |
Max Memory | 16GB soldered memory, not upgradable |
Storage | 512GB SSD M.2 2280 PCIe® 4.0x4 Performance NVMe® Opal 2.0 |
Storage Slot | One M.2 2280 PCIe® 4.0 x4 slot |
Max Storage Support | One drive, up to 2TB M.2 2280 SSD |
Optical | None |
Card Reader | None |
Audio Chip | High Definition (HD) Audio, Realtek® ALC3306 codec |
Speakers | Stereo speakers, 2W x2 woofers and 0.8W x2 tweeters, Dolby Atmos® |
Microphone | 4x, Array |
Camera | FHD 1080p + IR Hybrid with Privacy Shutter |
Battery | 57Wh |
Power Adapter | 65W USB-C® (3-pin) |
DESIGN |
Display | 14" WUXGA (1920x1200) IPS 400nits Anti-glare, 100% sRGB, Low Power, Touch |
Touchscreen | On-cell, 10-point Multi-touch |
Pen | Pen Not Supported |
Keyboard | Backlit, English |
Dimensions (WxDxH) | 315.6 x 222.5 x 15.36 mm (12.43 x 8.76 x 0.60 inches) |
Weight | Starting at 1.12 kg (2.48 lbs) |
Case Color | Deep Black, Paint |
Case Material | Carbon Fiber (Top), Aluminium (Bottom) |
SOFTWARE |
Operating System | Windows® 11 Pro, English |
Bundled Software | Intel® Connectivity Performance Suite |
CONNECTIVITY |
WLAN + Bluetooth | Intel® Wi-Fi® 6E AX211, 802.11ax 2x2 + BT5.3 |
WWAN | Non-WWAN |
SIM Card | None |
Ethernet | No Onboard Ethernet |
NFC | None |
Standard Ports | 1x USB 3.2 Gen 1 1x USB 3.2 Gen 1 (Always On) 2x Thunderbolt™ 4 / USB4® 40Gbps (support data transfer, Power Delivery 3.0 and DisplayPort™ 1.4a) 1x HDMI® 2.1, up to 4K/60Hz 1x Headphone / microphone combo jack (3.5mm) |
Optional Ports (configured) | None |
Docking | Various docking solutions supported via Thunderbolt™ / USB-C®. For more compatible docking solutions, please visit Docking for ThinkPad® X1 Carbon Gen 11 |
SECURITY & PRIVACY |
Security Chip | Discrete TPM 2.0 Enabled |
Physical Locks | Kensington® Nano Security Slot, 2.5 x 6 mm |
Smart Card Reader | None |
Fingerprint Reader | Touch Style, Match-on-Chip, Integrated in Power Button |
Other Security | Camera privacy shutter IR camera for Windows® Hello (facial recognition) Glance by Mirametrix® |
MANAGEABILITY |
System Management | Non-vPro® |
ACCESSORIES |
Bundled Accessories | None |
CERTIFICATIONS |
Green Certifications | ENERGY STAR® 8.0 EPEAT™ Gold Registered ErP Lot 6/26 RoHS compliant TCO Certified 9.0 |
Mil-Spec Test | MIL-STD-810H military test passed |
Other Certifications | Eyesafe® Certified 2.0 Intel® Evo™ Platform |
